Alinx ACU4EV User Manual page 23

level standard of BANK65 and BANK66 is determined by the VCCO_65
and VCCO_66 power supply of the carrier board, but cannot exceed +1.8V;
the level standard of MIO is also 1.8V.
Pin assignment of board to board connector J29
J29 Pin Signal Name
1 B65_L2_N
3 B65_L2_P
5
7 B65_L4_N
9 B65_L4_P
11
13 B65_L1_N
15 B65_L1_P
17
19 B65_L7_P
21 B65_L7_N
23
25 B65_L15_P
27 B65_L15_N
29
31 B65_L16_P
33 B65_L16_N
35
37 B65_L14_P
39 B65_L14_N
41
43 B65_L5_N
45 B65_L5_P
47
49 B65_L11_N
51 B65_L11_P
53
55 B65_L10_N
57 B65_L10_P
23 / 30
ZYNQ Ultrascale + FPGA Core Board ACU4EV User Manual
Pin Number
V9
U9
GND -
T8
R8
GND -
Y8
W8
GND -
L1
K1
GND -
N7
N6
GND -
P7
P6
GND -
M6
L5
GND -
T7
R7
GND -
K3
K4
GND -
H3
H4
Amazon Store:
Sales Email:
J29 Pin Signal Name
2 B65_L22_P
4 B65_L22_N
6 GND
8 B65_L20_P
10 B65_L20_N
12 GND
14 B65_L6_N
16 B65_L6_P
18 GND
20 B65_L17_P
22 B65_L17_N
24 GND
26 B65_L9_P
28 B65_L9_N
30 GND
32 B65_L3_N
34 B65_L3_P
36 GND
38 B65_L19_P
40 B65_L19_N
42 GND
44 B65_L18_P
46 B65_L18_N
48 GND
50 B65_L8_P
52 B65_L8_N
54 GND
56 B65_L24_N
58 B65_L24_P
