6 COMMISSIONING / STARTING
iBoost F200
6.11 The iBoost is fitted with a user interface, this has the following indicator lights
A) Green – illuminated when the mains power is supplied to the iBoost
B) Orange – illuminated when the pump is running
C) Red
The user interface also has a 'Reset' button (D), this is only functional when
the red 'Error' light is illuminated.
A
B
C
Fig. 14
– illuminated when the iBoost runs out of water and is in dry run
protection mode.
- 16 –
D
