Table Of Contents - Stuart Turner MAINSBOOST iBOOST F200 Installation, Operation & Maintenance Instructions Manual

PRODUCT DESCRIPTION
iBOOST F200
Water pressure and flow booster set with integral water storage tank and electric
motor driven centrifugal pump complete with an automatic control system, consisting
of flow switch, pressure switch, pressure vessel and electronic control. The design of
the tank incorporates an AF air gap for fluid isolation (BS EN 1717).
iBOOST V200
Water pressure and flow booster set with integral water storage tank and electric
motor driven centrifugal pump complete with an automatic variable speed control
system, consisting of pressure transducer and integral variable speed drive. The
design of the tank incorporates an AF air gap for fluid isolation (BS EN 1717).
APPLICATION
The Mainsboost iBoost 200 is designed to meet the demand of pressurised systems
in larger domestic applications where the existing mains water supply is insufficient.
Inlet pressures to the tank and ambient temperatures must not exceed the values
given in the technical specifications.
STORAGE
If this product is not to be installed immediately on receipt, ensure that it is stored in a
dry, frost and vibration free location in its original packaging.
CONTENTS
Page
Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Important Facts - read before commencing installation . . . . . . . . . . . . . . . . . . . . . .6
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Key Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Installation & Pump Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Electrical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Technical Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Warranty Policy Terms and Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
