Specifications and Regulatory Compliance

This appendix provides operating specifications for the Matrix N3 7C103 chassis, 7C203-1 power
supply module, and 7C403 fan tray. Enterasys Networks reserves the right to change the
specifications at any time without notice.
A.1 PHYSICAL SPECIFICATIONS
The physical specifications for the Matrix N3 7C103 chassis, the 7C203-1 power supply module,
and the 7C403 fan tray are as follows:
7C103 Chassis
Item
Physical
Dimensions:
Weight (with factory installed fan tray):
Mean Time Between Failures (MTBF):
7C203-1 Power Supply Module
Item
Physical
Dimensions:
Weight:
Mean Time Between Failures (MTBF):
Specification
35.56 H x 44.45 W x 49.53 (cm)
14.0 H x 17.5 W x 19.5 D (in.)
19.1 kg (42.0 lb)
792,909 hours
Specification
41.05 H x 6.04 W x 28.44 D (cm)
16.16 H x 2.38 W x 11.20 D (in.)
5.5 kg (12.0 lb)
200,000 hours
