Installation Requirements and Guidelines

This chapter describes the following:
•
Site guidelines that must be met before installing the N3 chassis into a rack or cabinet
•
N3 chassis configuration guidelines
•
Operating specifications for the N3 chassis enclosure and power supply modules
Electrical Hazard: Only qualified personnel should install or service this unit.
Riesgo Eléctrico: Nada mas personal capacitado debe de instalar o darle servicio a esta unida.
Elektrischer Gefahrenhinweis: Installationen oder Servicearbeiten sollten nur durch
ausgebildetes und qualifiziertes Personal vorgenommen werden.
2.1

INSTALLATION SITE GUIDELINES

When determining an installation site for the N3 chassis, follow the guidelines outlined below.
•
For proper cooling, there must be a minimum amount of clearance 15.2 centimeters (6 inches)
behind the chassis and 5.08 centimeters (2 inches) of clearance on either side of the chassis.
•
If installing the N3 chassis as a freestanding unit on a shelf, ensure that the shelf can support a
minimum weight of approximately 32.4 kilograms (71 pounds) per fully loaded chassis plus the
weight of the connected network cables. The weight includes the chassis, fan tray, two power
supplies, and three modules.
•
For access to the rear of the chassis to maintain, remove, or replace the fan tray, allow an area of
48.26 centimeters (19 inches) wide by 61 centimeters (24 inches) deep.
•
If installing the N3 chassis in an equipment rack, ensure that the rack can support and remain
stable with the chassis installed.
