3.4.2

Reinstalling the Fan Tray

To reinstall the fan tray, refer back to
1. Locate the ESD wrist strap shipped with the N3 chassis. Attach the ESD wrist strap to your wrist
and plug the cable from the ESD wrist strap into the ESD grounding receptacle at the front
upper-right corner of the chassis.
2. Hold the fan tray by its handles and align the four fan tray captive screws with the tapped holes
in the rear of the chassis.
Caution: Although the fan tray has a self-aligning power connector that mates with the one in the
rear of the chassis, do not force the fan tray into place, as it may damage the chassis and fan tray.
Precaución: Aunque la bandeja cuenta con un conector de alimentación que se alinea
automáticamente con el que está en la parte trasera del chasis, no debe forzar la bandeja de
ventiladores en su lugar, ya que podría dañarla o dañar el chasis.
3. Slide the fan tray into the chassis until the faceplate of the tray is flush with the rear of the N3
chassis. If there is strong resistance, remove the fan tray and reinsert it.
4. Once the tray is in place, tighten the four captive screws to secure the tray to the rear of the
chassis.
Removing and Reinstalling the Fan Tray
Figure 3-7 and proceed as follows:
Chassis Setup 3-13
