Introduction
This chapter explains how to set up and cable the MiniArray
This product, as received by the end-user, is ready to be connected to the end-user's
Ethernet concentrator and is preconfigured to operate as a communication server once your
modem connections are made, VGA monitor and keyboard are linked up, the system booted,
and some basic information entered. To connect the cables to the SBC, NIC, or ISI board,
refer to the "Cable Connections" section of this chapter.
Unpacking
Check the items on the MiniArray
options and accessories. Unpack and inspect the cabinet for visible shipping damage. If
damage is observed, do not power-on the unit; contact Multi-Tech's Tech Support for advice.
If no damage is observed, place the MiniArray
Safety Warning AC Power
Locate the AC outlet near the communication equipment. The AC power cord is your main
AC disconnecting device and must be easily accessible at all times. For your safety, the
power cord provided with your system has a grounded plug. Always use the power cord with
a properly grounded wall outlet, to avoid the risk of electrical shock.
Lithium Battery Caution
A lithium battery on the product provides backup power for the devices timekeeping
capability. The battery has an estimated life expectancy of ten years.
When the battery starts to weaken, the date and time may be incorrect. If the battery fails,
the unit must be sent back to Multi-Tech systems for battery replacement.
Warning: There is danger of explosion if the battery is incorrectly replaced.
Laser Safety Caution
Class 1 LED Product.
The CD-ROM drive contains a laser system and is classified as a " Class 1 Laser Product"
under a U.S. Department of Health and Human Services (DHHS) Radiation Performance
standard according to the Radiation Control for Health and Safety Act of 1968.
Should the unit ever require maintenance, contact an authorized repair location.
