Tiberius Tunable Femtosecond Ti:Sapphire Laser
Specifications
Chapter 9
9.1.

Laser Specifications

Tuning Range
Pulse Width
Average Power
1
Noise
Repetition Rate
Beam Diameter (1/e
2
M
Pointing Stability During Tuning
9.2.

Electrical Requirements

Input Voltage
Frequency
Power Consumption
1
Measurement Bandwidth: 10 Hz - 1 MHz
Laser Specifications
2
)
Figure 1 Typical Tuning Curve for the Tiberius Laser
Electrical Requirements
Chapter 9: Specifications
720 - 1060 nm
140 fs
> 1.0 W at 720 nm
> 2.3 W at 800 nm
> 1.4 W at 920 nm
> 0.5 W at 1000 nm
> 0.3 W at 1040 nm
< 0.15% (RMS)
77 MHz (nominal)
1.5 mm (nominal)
< 1.2 at 800 nm
< 50 µrad per 100 nm
100 - 240 V
50 - 60 Hz
1.2 kW (Max)
Page 33
