1.6.4

Serial Port Parameters Menu

MANAGEABLE HUB
The Serial Port Parameters Menu, selectable from the Configuration Main
Menu, brings up software for verifying or for setting the serial port
parameters.
Serial Port Parameters Menu
baud
stop bits
Select a parameter [main ==> root menu OR ? ==> help]
SERIAL >
The Serial Parameters Menu comes up with standard values for the
following serial port parameters:
baud = 9600
stop bits = NONE or 1
data bits = 7 or 8
parity = NONE or 1
1. INTRODUCTION
= 9600 data bits
= 1 parity
Transmission speed, in bits per
second
Serial protocol definition entry
Serial protocol definition entry
Optional error checking entry.
= 8
= NONE
1-17
