1.2

16-Port 10BaseT Repeater

Connectors
Indicators
1-4
The StackMaster™ 16-Port 10BaseT Repeater hub supports sixteen RJ-45
10BaseT connections to either shielded or unshielded twisted pair.
Additionally, the StackMaster™ 16-Port 10BaseT hub supports installation
of an SNMP Management Board that allows the StackMaster™ 16-Port
10BaseT hub to manage the entire StackMaster™ Stack.
Sixteen (16) RJ-45 connectors are provided at the front of the 16-Port
10BaseT Repeater hub.
StackMaster™ 16 Port Manageable 10BaseT Hub
T R A N S I T I O N
n e t w o r k s
A power connector, DB9 serial port connector, AUI port connector, and
Cascade (bus) connector are provided at the back of the 16-Port 10BaseT
hub.
CASCADE CONNECTORS
A
SERIAL
B
When the StackMaster™ 16-Port 10BaseT Repeater hub is powered, the
Power indicator is illuminated. Combination Link/Partition LEDs above
each of the sixteen RJ-45 connectors indicate link and partition status for
each of the sixteen 10BaseT connections:
green LED:
red LED:
StackMaster™ 16 Port Manageable 10BaseT Hub
Expansion Enable
T R A N S I T I O N
n e t w o r k s
Power
1 2 3 4 5
Link/Partition
Power
Expansion Enable Reset
TRANSITION
7090 Shady Oak Road
E N G I N E E R I N G , I N C .
Mpls, MN 55344
AUI AUX
Model#: SMHB-E-TBT-16
good link
partition
1 2 3 4 5
Link/Partition
Power
Reset
11
6 7 8 9 10 11 12 13 14
Caution : For continued protection
against risk of fire, replace only with same
type and rating of fuse : 250V 2A.
Caution : Disconnect power before replacing fuse.
ATTENTION: Couper le courant avant de replacer
le fusible.
Input Power: 100-240 V
2A, 250V
50/60 Hz
0.5 A
6 7 8 9 10 11 12 13 14 15
12 13
StackMaster™
15 16
Expansion Card
Status
1 2 3 4
5 6 7 8
220-240
110-120
16
Expansion Card
Status
1 2 3 4
5 6 7 8
