3.2. Operating Elements

The following table describes the NB3710 status indicators.
Label Color
Status blinking The device is busy due to startup, software or configu-
[1]
Mob1
blinking Mobile connection 1 is being established.
[1]
Mob2
blinking Mobile connection 2 is being established.
[1]
WLAN1
blinking WLAN connection 1 is being established.
[1]
WLAN2
blinking WLAN connection 2 is being established.
GNSS
blinking GNSS is searching for satellites.
Voice
DO1
NB3710 User Manual 4.0
State Function
ration update.
on The device is ready. The captions of the top bank apply.
on The device is ready. The captions of the bottom bank
apply.
on Mobile connection 1 is up.
off Mobile connection 1 is down.
on Mobile connection 2 is up.
off Mobile connection 2 is down.
on WLAN connection 1 is up.
off WLAN connection 1 is down.
on WLAN connection 2 is up.
off WLAN conne ction 2 is down.
on GNSS is turned on and a valid NMEA stream is avail-
able.
off GNSS is turned off or no valid NMEA stream is avail-
able.
on A voice call is currently active.
off No voice call is active.
on Normally open output port 1 is closed.
off Normally open output port 1 is open.
