Ibis Port Specification; Pin Assignments Of Ibis Port Signals (Ep1 / Ep2); Non-Isolated Rs-232 Port Specification - NetModule NB3710 User Manual

Feature
Galvanic isolation
EP Pins Signal
1 / 5
2 / 6
3 / 7
4 / 8
Table 3.22.: Pin Assignments of IBIS Port Signals (EP1 / EP2)
Non-isolated 3-wire RS-232 Port Specification
The non-isolated 3-wire RS-232 port has the following specification (Option S):
Feature
Protocol
Baud rate
Data bits
Parity
Stop bits
Software flow control
Hardware flow control
Galvanic isolation
Table 3.23.: Non-isolated RS-232 Port Specification
EP Pins Signal
1 / 5
2 / 6
NB3710 User Manual 4.0
Specification
1500 V
DC
Table 3.21.: IBIS Port Specification
Call Signal
Call GND ('Aufrufbus')
Reply GND ('Antwortbus')
Reply Signal
Specification
3-wire RS-232: GND, TXD, RXD
300, 1 200, 2 400, 4 800, 9 600, 19 200,
38 400, 57 600, 115 200, 230 400, 460 800
7 bit, 8 bit
none, odd, even
1, 2
None, XON/XOFF
None
None
GND
TxD
