Power Supply; Ethernet Port Specification; Pin Assignments Of Ethernet Connectors - NetModule NB3710 User Manual

Feature
Isolation
Speed
Mode
Crossover
Pin Assignment on M12, 4 poles, D-coded female
Pin Signal
1 Tx+
2 Rx+
3 Tx
4 Rx
Table 3.9.: Pin Assignments of Ethernet Connectors

3.3.7. Power Supply

The power input has the following specifications:
Feature
Power supply nominal voltages
Voltage range
Max. power consumption
Galvanic isolation
Power interruption
Supply change over
Connector type
NB3710 User Manual 4.0
Specification
1500 V
10/100 Mbps
Half- & Full-Duplex
Automatic MDI/MDI-X
Table 3.8.: Ethernet Port Specification
Specification
24 V
DC
(according to EN 50155)
12 V
DC
15 W
yes, 1500 V
(according to EN 50155 & EN 60950)
Class S2: Sustains power interruptions up
to 10 ms
No batteries included
Class C1: 0.6 U
terruption)
M12, 4 poles, A-coded male
DC
Pinning
, 36 V and 48 V
DC DC
to 60 V ( 15% / +5%)
DC
DC
during 100 ms (w/o in-
n
