PARTS LIST

ITEM QTY REFERENCE
1 1 PCB
2 1 C1
3 1 C2
4 1 C3
5 1 C4
6 1 C5
7 1 C6
8 1 C7
9 1 C8
10 1 C9
11 1 INPUT
12 1 L1
13 1 OUTPUT
14 1 P1
15 1 R1
16 6 R6, R8, R10,
R11, R12, R13
17 3 R14, R15, R16
18 2 R17, R18
19 1 R2
20 1 R3
21 1 R4
22 1 R5
23 2 R7, R9
24 1 U1
25 1 VIOC
Note 1. These items are not stuffed (DNI).
DEMO MANUAL SCP-LT8618-BEVALZ
PART DESCRIPTION
PRINTED CIRCUIT BOARD
CAP 22uF 63V ALUM 8x10.5
CAP 1uF 100V CER, X7R 1206
CAP 0.1uF 100V CER X7R 0603
CAP 47nF 50V CER X7R 0603
CAP MLCC 0603 (Note 1)
CAP 10uF 50V X5R 1206
CAP 1uF 10V X7R 0603
CAP 10nF 50V CER X7R 0603
CAP 4.7uF 50V CER X7R 1206
CONN MALE 3POS 2.54MM PITCH R/A
IND 33uH 0.42A 0.66OHM
CONN FEMALE 3POS 2.54MM PITCH R/A
CONN-PCB 3POS HEADER WIRE TO BRD WAFER ASSY
STRAIGHT 2MM PITCH (Note 1)
RES 1M 1%THICK FILM 0805
RED THICK FILM 0805 (Note 1)
RES 0 OHM 1% 3/4W 0612
RES THICK FILM 0612 (Note 1)
RES 18.2K 1% THICK FILM 0805
RES 49.9K 1% THICK FILM 0805
RES 1M 1% THICK FILM 0805
RES 187K 1% THICK FILM 0805
RES 0-OHM 1%THICK FILM 0805
IC-ADI HIGH EFFICIENCY 60V/100MA SYNCHRONOUS BUCK ANALOG DEVICES LT8618EDDB#PBF
CONN FEMALE 2POS 2.54MM PITCH R/A
MANUFACTURER/PART NUMBER
ANALOG DEVICES 08_059761a
SUN ELECTRONIC 63CE22BSA
TAIYO YUDEN HMK316B7105KL-T
SAMSUNG CL10B104KC8NNNC
KEMET C0603X473K5RACTU
N/A
SAMSUNG CL31A106MBHNNNE
SAMSUNG CL10B105KP8NNNC
YAGEO CC0603KRX7R9BB103
SAMSUNG CL31B475KBHNNNE
SULLINS PBC03SBAN
WURTH ELEKTRONIK 44031330
SULLINS PPPC031LGBN-RC
MOLEX 53253-0370
YAGEO RC0805JR-071ML
N/A
VISHAY RCL06120000Z0EA
N/A
PANASONIC ERJ-6ENF1822V
PANASONIC ERJ-3EKF4992V
PANASONIC ERJ-6ENF1004V
PANASONIC ERJ-6ENF1873V
VISHAY CRCW08050000Z0EA
SULLINS PPPC021LGBN-RC
