PPT 8800 Series Product Reference Guide for Embedded Windows

TCM Error Messages

TCM validates the cells in your partition table when you press the Enter button. Cells
highlighted in red contain an error. Partition loading is disabled until all errors are corrected.
The errors that TCM may encounter and possible solutions are described in
Error
Error - Partition Size
Error - Image Larger than
Partition
Error - Total size of all
FFS Partition
Error - Source/
Destination Path
Verification
For more information on FFS Partitions and Non-FFS Partitions, see Flash Storage on
page 9-24.

Creating and Loading a Splash Screen

To generate a custom splash screen, use a bitmap editor.
1. Create a color bitmap with dimensions of BX x BY where:
• BX is less than or equal to 240 pixels
• BY is less than or equal to 320 pixels
Note: For best quality use a relatively high resolution color image (256
color). Lower resolution images also work.
9-22
Table 9-3. TCM Error Messages
The size of a partition must be an integral multiple of the
FFSSectorSizeInBytes specified by the .ini file. When the user enters a
partition size, TCM rounds up to the next highest integral multiple of the
sector size and displays this value in the partition table grid. This error
check is made upon value entry, independent of the Execute button.
If the required size of the binary image file is larger than the associated
partition size, the Partition Size cell in the partition grid turns red to
highlight the error. The Required Size cell indicates the actual size
required.
If the total memory allocated to the 3 FFS partitions is greater than the
total Flash Memory on the terminal, the Used FFS Memory display box
turns red. Decrease the size of one or more of the partitions, then
recheck the configuration using the Execute button.
If the directory paths specified by the Source and Destination cells do
not exist, the cell containing the non-existent path turns red to highlight
the error.
Description/Solution
®
CE .NET
Table 9-3.
