  • Page 1 P 370/470 RF Scanner Product Reference Guide...
  • Page 2 P 370/470 RF Scanner Product Reference Guide 72-38495-01 Revision A — February 2000 Symbol Technologies, Inc. One Symbol Plaza, Holtsville N.Y. 11742-1300...

  • Page 3: Product Reference Guide

    P 370/470 RF Scanner Product Reference Guide 70-38495-01 Revision A February 2000...
  • Page 4 The software is provided strictly on an “as is” basis. All software, including firmware, furnished to the user is on a licensed basis. Symbol grants to the user a non-transferable and non-exclusive license to use each software or firmware program delivered hereunder (licensed program).

  • Page 5: Table Of Contents

    Symbol Support Centers ........
  • Page 6 Scan the Entire Symbol ........
  • Page 7 Contents RS-232C Host Types............5-14 Host Response Timeout .
  • Page 8 Symbol Code ID Characters ........
  • Page 9 Contents MCL-Net Baud Rate ............5-95 MCL-Net Baud Rate (Continued) .
  • Page 10 P 370/470 RF Scanner Product Reference Guide viii...

  • Page 11: About This Manual

    About This Manual Introduction The P 370/470 RF Scanner Product Reference Guide provides general instructions for setup, operation, troubleshooting, maintenance, and programming the P 370 industrial environment and P 470 retail environment RF scanners. Chapter Descriptions Chapter 1, The 370/470 RF Scanner, describes the scanner, the battery, and the PL 370/470 Cradle.

  • Page 12: Related Publications

    Call the Support Center from a phone near the scanning equipment so that the service person can try to talk you through your problem. If the equipment is found to be working properly and the problem is symbol readability, the Support Center will request samples of your bar codes for analysis at our plant.
  • Page 13 About This Manual United Kingdom Asia/Pacific Symbol Technologies Symbol Technologies Asia, Inc. Symbol Place 230 Victoria Street #04-05 Winnersh Triangle, Berkshire RG41 5TP Bugis Junction Office Tower United Kingdom Singapore 188024 0800 328 2424 (Inside UK) 337-6588 (Inside Singapore) +44 118 945 7529 (Outside UK)
  • Page 14 P370/470 RF Scanner Product Reference Guide Germany Italy Symbol Technologies GmbH Symbol Technologies Italia S.R.L. Waldstrasse 68 Via Cristoforo Columbo, 49 D-63128 Dietzenbach, Germany 20090 Trezzano S/N Navigilo 6074-49020 (Inside Germany) Milano, Italy +49-6074-49020 (Outside Germany) 2-484441 (Inside Italy) +39-02-484441 (Outside Italy)

  • Page 15: Warranty

    This warranty is provided to the original owner only and is not transferable to any third party. It shall not apply to any product (i) which has been repaired or altered unless done or approved by Symbol, (ii) which has not been maintained in accordance with any operating or handling instructions supplied by...

  • Page 16: General

    P370/470 RF Scanner Product Reference Guide Symbol’s Customer Service organization offers an array of service plans, such as on-site, depot, or phone support, that can be implemented to meet customer’s special operational requirements and are available at a substantial discount during warranty period.

  • Page 17: Introduction

    Chapter 1 The 370/470 RF Scanner Chapter Contents Introduction ..............1-3 Rechargeable Battery .
  • Page 18 P 370/470 RF Scanner Product Reference Guide...

  • Page 19: Introduction

    The 370/470 RF Scanner Introduction The RF scanner is a revolutionary, cordless approach to capturing bar coded data. The scanner communicates with your host computer through a low-power radio transmission instead of through a cable. With the RF scanner, you are free to scan and transmit without a physical cable to limit your movement, from as far away as 100 feet (30.5 meters), depending on your environment.

  • Page 20: Accessories

    P 370/470 RF Scanner Product Reference Guide The cradle also provides power for charging the scanner’s battery (in the scanner). The cradle has a charge status indicator light that shows the status of the battery charging (Refer to Table 4-1 on page 4-4). Figure 1-1.
  • Page 21 The 370/470 RF Scanner Lanyard, p/n 21-37101-01 Protective boot, p/n 11-36471-01 Desk Stand, p/n 21-33687-01 Spare power supply, p/n 59-14000-101.
  • Page 22 P 370/470 RF Scanner Product Reference Guide...
  • Page 23 Chapter 2 Set Up Chapter Contents Introduction ..............2-3 Unpacking .
  • Page 24 P 370/470 RF Scanner Product Reference Guide...

  • Page 25: Introduction

    Remove the scanner from its packing and inspect it for damage. If the scanner was damaged in transit, call one of the telephone numbers listed in the section Symbol Support Centers on page x. KEEP THE PACKING. It is the approved shipping container and should be used if you ever need to return your equipment for servicing.
  • Page 26 P 370/470 RF Scanner Product Reference Guide RS-232 Connection 1. Make sure all host devices are powered down. 2. Plug the connector at the end of the cradle’s cable into an appropriate RS-232 receiving port on the host device. 3. Plug the other end of the cable into the COM1 connector on the cradle. COM1 Power port Figure 2-1.
  • Page 27 Set Up Using A Synapse Cable 1. Make sure all host devices are powered down. 2. Connect the Synapse Adapter cable to COM1 in the cradle (see Figure 2-1 on page 2-4). 3. Connect the Adapter cable to the Synapse Interface cable. 4.

  • Page 28: Wall Mounting

    P 370/470 RF Scanner Product Reference Guide Wall Mounting Before wall-mounting the cradle, the scanner support tab must be changed from the desk- mount position to the wall-mount position. 1. Lift the scanner support tab out of the top part of the cradle and replace it in the wall- mount position.

  • Page 29: Pairing The Scanner With The Cradle

    Set Up Figure 2-6. Securing Cradle to Wall 5. Position the antenna vertically (pointing toward the ceiling). 6. Place the scanner in the cradle. Pairing the Scanner with the Cradle The wireless “connection” between the scanner and the cradle is the low power radio transmission through RF transceivers in the both the scanner and cradle.

  • Page 30: Optimizing Rf Performance

    P 370/470 RF Scanner Product Reference Guide Optimizing RF Performance The RF scanner is equipped with a low power 2.4 GHz radio. Depending on environmental conditions, it can have an RF transmission range of 100 feet (30.5 meters). Where environmental objects affect RF range and performance, do the following when you install the scanning system.

  • Page 31: Using The Ubc 2000

    In typical applications, the batteries should last about two years. As they begin to age, batteries do not hold a charge as long as when they were fresh; you have to charge them more often. A new battery (p/n 50-14000-079) can be obtained from Symbol Technologies. See your Symbol representative for more information.
  • Page 32 P 370/470 RF Scanner Product Reference Guide 3. Information is exchanged (addressing, RF channels, etc.) between the scanner and the cradle. This occurs in a few seconds if the scanner is in the cradle or up to a minute if not in the cradle. 4.
  • Page 33 Scan the Entire Symbol ........
  • Page 34 P 370/470 RF Scanner Product Reference Guide...

  • Page 35: Chapter 3. Operation

    Symbol Support Center. 1. Make sure the bar code is in the correct scanning range. Aim and press the trigger. The scanner has read the symbol when: " You hear a beep. " The LED above the screen turns green.

  • Page 36: Scan The Entire Symbol

    P 370/470 RF Scanner Product Reference Guide Scan the Entire Symbol Your scan beam must cross every bar and space on the symbol. The larger the symbol, the farther away you should hold the scanner. Hold the scanner closer for symbols with bars that are close together.

  • Page 37: Keypad Operation

    Operation Keypad Operation In the default application supplied with the RF scanner, the keypad is enabled. If your application has enabled the keypad, you can enter the bar code’s data using the keypad on the top of the scanner. To enter numeric characters, press the number key on the keypad. A high-pitched click lets you know that the entry was accepted.
  • Page 38 P 370/470 RF Scanner Product Reference Guide Figure 3-3. Scanner Keypad...

  • Page 39: Scanning Transmission Range

    Operation Scanning Transmission Range RF Communication Errors RF communication errors occur when the scanner is out of range from the cradle during a scan data transmission attempt. A communication error is indicated by 4 beeps (LO HI LO HI) after a bar code is scanned, although the bar code data may appear on the host display. This happens when the cradle receives the bar code data but the scanner did NOT get the host response from the cradle, and therefore timed out.

  • Page 40: Pos Application

    P 370/470 RF Scanner Product Reference Guide Symbol Technologies Phaser RF Figure 3-4. Banner Screen After 10 seconds, the System Banner is replaced by the system initialization screen: SYMBOL TECHNOLOGIES INITIALIZING ... Figure 3-5. Initialization Screen and finally, the scanner enters the POS scanning screen.
  • Page 41 Operation within the first 10 seconds after the power up beep (while the Banner Screen is still shown). The scanner displays: Phaser Setup 0. System Setup Figure 3-8. Setup Screen Pressing the Up and Down keys scrolls through the menu of available setup options: 0.
  • Page 42 If the channel is not legal to use in your country, an error beep will be heard instead of a successful warble. Contract the Symbol Support Center if you don not know what the available channels are for your country.
  • Page 43 Operation Set Contrast Sets the contrast of the display. The scanner displays its current contrast level, and by using the up and down arrow keys the user can change the contrast. The default contrast level is 4, and the range is from 0 to 7, with 0 being the lightest and 7 being the darkest. To cancel the change, press the <FN><BK>...
  • Page 44 P 370/470 RF Scanner Product Reference Guide 1. Data As Is 2. PREFIX><DATA> 3. DATA><SUFFIX> 4. PFX><DATA><SFX> 5. Edit Prefix Code 6. Edit Suffix Code Figure 3-13. Set Host Type Screen The first option, Data As Is, indicates that the scanned data will be transmitted to the host with no modifications.
  • Page 45 Operation Press the <ENTER> key to confirm the choice (Yes) or the <BK> key to cancel the choice (No). If you are to enter the MCLNet Host Mode, a confirmation screen displays warning that data may be lost. Press the <ENTER> key to continue or the <BK> key to cancel. Set Default App Restores the default application described above.
  • Page 46 P 370/470 RF Scanner Product Reference Guide Autoload App? Enabled Figure 3-17. Autoload Application Screen Selecting will enable this feature; with disable this feature. Note that this Enabled Disabled option ONLY affects the default application, and does not affect any user applications. Parameter Control These functions allow you to control the scanner parameters.
  • Page 47 Operation Battery Status Good Figure 3-20. Battery Status Screen Version Displays the current version of MCL the scanner is running. System: XXXXXXXX MCL: X.X Figure 3-21. Version Screen Return to App Exits the system setup mode and returns to the application (either the default application described above, or any downloaded application).

  • Page 48: Decode Zone

    P 370/470 RF Scanner Product Reference Guide Decode Zone 15.6 in. 39.6 cm 10 in. 25.4 cm Width 5 in. 12.7 cm 0 in. 0 cm Field 5 in. 12.7 cm 5 mil 10 in. 7.5 mil 25.4 cm 10 mil 15.6 in.

  • Page 49: Troubleshooting

    Check that the scanner is successfully paired with the cradle. Check that the cradle is powered up and that it’s cable connections are secure. Note: If after performing these checks the symbol still does not scan, contact your distributor or call the Symbol Support Center. See Symbol Support Centers on page page x for the telephone number.

  • Page 50: Installations In Spectrum24 Or Other 2.4Ghz Environments

    P 370/470 RF Scanner Product Reference Guide Installations in Spectrum24 or Other 2.4GHz Environments When installing the RF scanner system in a Spectrum24 environment, follow the following general rules: 1. RF scanner location relative to a Spectrum24 Access Point can increase performance. Network products use Access Points (base stations) that are positioned fixed throughout the facility.
  • Page 51 Chapter 4 Maintenance And Specifications Chapter Contents Introduction ..............4-3 Maintenance.
  • Page 52 P 370/470 RF Scanner Product Reference Guide...

  • Page 53: Chapter 4. Maintenance And Specifications

    Maintenance And Specifications Introduction This chapter explains how to maintain your scanner and the specifications for it. Maintenance Do not allow any abrasive material to touch the scanner window. Remove any dirt particles with a damp cloth. Wipe the scanner window using a damp cloth, and if necessary, a non-ammonia based detergent.

  • Page 54: Replacing The Battery

    P 370/470 RF Scanner Product Reference Guide 2. Slide the battery towards the bottom of the scanner and then pull the bottom of the battery back and out of the scanner. Figure 4-2. Pulling the Battery Out Replacing the Battery 1.

  • Page 55: Technical Specifications

    Maintenance And Specifications Technical Specifications Table 4-2. T echnical Specifications Item Description Decode Capability The RF scanner can be programmed to decode the following code types: UPC/EAN, Bookland EAN, Code 11, Code 39, Code 39 Full ASCII, Trioptic Code 39, Code 93, Codabar, Interleaved 2 of 5, Code 128, EAN 128, Discrete 2 of 5, MSI Plessey, and Coupon Code.
  • Page 56 P 370/470 RF Scanner Product Reference Guide Table 4-2. Technical Specifications (Cont’d) Item Description Durability (Scanner) P370 (Industrial) 6-ft. drop to concrete 1.8 m P 470 (Retail) 5-ft. drop to concrete 1.5 m Dimensions Height 7.0 in. (17.8 cm) Width 9.2 in.

  • Page 57: Cradle Pin-Outs

    Maintenance And Specifications Cradle Pin-outs The following table shows the pin-outs for COM1 on the cradle. Table 4-3. Pin-outs Cradle Pin 1 Reserved VCC (Out) Ground Synapse Data Synapse Clock RXD IN TXD OUT DTR (Tied HI) CTS - IN RTS - OUT...

  • Page 58: Beeper Indications

    Beeper Sequence Indication Message Standard Use Short high tone A bar code symbol was decoded (if decode beeper is enabled). 4 long low beeps A host transmission error occurred. Data Error 00003 during transmit. was not successfully sent to the host Error 00009 during transmit.
  • Page 59 Maintenance And Specifications Table 4-4. Beeper Indications (Cont’d) Default Application Display Beeper Sequence Indication Message Lo/Hi tone Input error, incorrect bar code or “Cancel” scanned, wrong entry, incorrect bar code programming sequence; remain in program mode. Hi/Lo tone Keyboard parameter selected. Enter value using bar code keypad.
  • Page 60 P 370/470 RF Scanner Product Reference Guide 4-10...
  • Page 61 Chapter 5 Parameter Menus Chapter Contents Introduction ..............5-5 Operational Parameters .
  • Page 62 P 370/470 RF Scanner Product Reference Guide Enable/Disable EAN-8/EAN-13 ........... 5-31 Enable/Disable Bookland EAN .
  • Page 63 Symbol Code ID Characters ........
  • Page 64 P 370/470 RF Scanner Product Reference Guide...

  • Page 65: Introduction

    Parameter Menus Introduction This chapter has the optional parameter bar codes necessary to program the RF scanner. Operational Parameters The RF scanner is shipped with the settings shown in Table 5-1. These default values are stored in non-volatile memory and are preserved even when the scanner is powered down. You can change these default values by scanning the appropriate bar codes included in this manual.
  • Page 66 P 370/470 RF Scanner Product Reference Guide The following table lists the defaults for all parameters. If you wish to change any option, scan the appropriate bar code(s). Table 5-1. Default Table Parameter Default Page Number Set Default Parameter All Defaults 5-11 RS-232 Host Type Standard...
  • Page 67 Parameter Menus Table 5-1. Default Table (Continued) Parameter Default Page Number UPC/EAN UPC-A Enabled 5-30 UPC-E Enabled 5-30 UPC-E1 Disabled 5-30 EAN-8 Enabled 5-31 EAN-13 Enabled 5-31 Bookland EAN Disabled 5-32 Decode UPC/EAN Supplementals Ignore 5-33 Decode UPC/EAN Supplemental 5-34 Redundancy Transmit UPC-A Check Digit Enabled...
  • Page 68 P 370/470 RF Scanner Product Reference Guide Table 5-1. Default Table (Continued) Parameter Default Page Number Code 128 Code 128 Enabled 5-46 UCC/EAN-128 Enabled 5-47 Code 39 Code 39 Enabled 5-48 Trioptic Code 39 Disabled 5-49 Set Length(s) for Code 39 2 to 55 5-51 Code 39 Check Digit Verification...
  • Page 69 Parameter Menus Table 5-1. Default Table (Continued) Parameter Default Page Number Discrete 2 of 5 Discrete 2 of 5 Disabled 5-66 Set Length(s) for D 2 of 5 5-67 Codabar Codabar Disabled 5-69 Set Lengths for Codabar 5-55 5-71 CLSI Editing Disabled 5-72 NOTIS Editing...
  • Page 70 P 370/470 RF Scanner Product Reference Guide Table 5-1. Default Table (Continued) Parameter Default Page Number RS-232C RS-232 Host Type Standard 5-14 Baud Rate 9600 5-84 Parity None 5-85 Check Receive Errors Disabled 5-87 Hardware Handshaking None 5-89 Software Handshaking None 5-90 Host Serial Response Time-out...

  • Page 71: Set Default Parameter

    Parameter Menus Set Default Parameter Scanning this bar code returns all parameters to the values listed in Table 5-1. SET ALL DEFAULTS 5-11...

  • Page 72: Host Type

    P 370/470 RF Scanner Product Reference Guide Host Type RS-232C Host Types Most RS-232C hosts work fine with the default settings, however, three RS-232C hosts are set up with their own parameter default settings. Selecting the ICL, Fujitsu or Nixdorf RS- 232C host interface sets the defaults listed below.

  • Page 73: Rs-232C Host Types

    Parameter Menus Host Type RS-232C Host Types Selecting the ICL, Fujitsu, or Nixdorf RS-232C host interface enables the transmission of Code ID Characters as listed below. These Code ID Characters are not programmable and are separate from the Transmit Code ID feature. The Transmit Code ID feature should not be enabled for these hosts.

  • Page 74: Rs-232C Host Types

    P 370/470 RF Scanner Product Reference Guide Host Type RS-232C Host Types Scan the appropriate bar code below to select an RS-232C Host Interface. STANDARD RS-232C ICL RS-232C NIXDORF RS-232C Mode A NIXDORF RS-232C Mode B FUJITSU RS-232C 5-14...

  • Page 75: Host Response Timeout

    Parameter Menus Host Response Timeout This parameter indicates how long the scanner will wait for a response from the cradle, after the cradle has sent its data to the attached host device. The timeout ranges from 5 seconds to 64 seconds, in 1 second increments. The default is 5 seconds.To change the timeout value, scan the bar code below, then scan two bar codes using the Numeric Bar Codes on page 5- 102.

  • Page 76: Rf Channel

    P 370/470 RF Scanner Product Reference Guide RF Channel Select the RF channel for the radio transmission and reception. The channel ranges are nation dependent. To enter a range, scan the bar code below followed by 2 digits from the numeric bar code section (starting on page 5-102) to set the desired channel.
  • Page 77 Parameter Menus 5 RETRIES 6 RETRIES 7 RETRIES 8 RETRIES 5-17...

  • Page 78: Sleep Time

    P 370/470 RF Scanner Product Reference Guide Sleep Time Scan the bar code below to select how long the scanner will “stay awake” (not power down) in seconds after a trigger pull or a key press. First scan this bar code, then enter a range from 05 to 32, using the Numeric Bar Codes on page 5-102.

  • Page 79: Decimal Separator

    Parameter Menus Decimal Separator Scan the appropriate bar code below to select what separator to display when you hit the decimal point key on the keypad. Choose DECIMAL POINT (.) or COMMA (,). DECIMAL POINT (.) COMMA (,) 5-19...

  • Page 80: Key Click

    P 370/470 RF Scanner Product Reference Guide Key Click Scan the appropriate bar code below to select whether the keypad click is enabled or not. Choose ENABLE or DISABLE. ENABLE DISABLE 5-20...

  • Page 81: Beeper Tone

    Parameter Menus Beeper Tone Scan the appropriate bar code below to select a decode beep frequency (tone). Choose LOW FREQUENCY, MEDIUM FREQUENCY, or HIGH FREQUENCY. LOW FREQUENCY MEDIUM FREQUENCY HIGH FREQUENCY 5-21...

  • Page 82: Beeper Volume

    P 370/470 RF Scanner Product Reference Guide Beeper Volume Scan the appropriate bar code below to select a beeper volume. Choose LOW VOLUME, MEDIUM VOLUME, or HIGH VOLUME. LOW VOLUME MEDIUM VOLUME HIGH VOLUME 5-22...

  • Page 83: Power Detect Beep

    Parameter Menus Power Detect Beep Scan the appropriate barcode below to enable or disable the Power Detection Beep. POWER DETECT BEEP DISABLED POWER DETECT BEEP ENABLED 5-23...

  • Page 84: Laser On Time

    P 370/470 RF Scanner Product Reference Guide Laser On Time This parameter sets the maximum time decode processing continues during a scan attempt. It is programmable in 0.1 second increments from 0.5 to 9.9 seconds. Scan the bar code below to set a Laser On Time. Next scan two numeric bar codes beginning on page 5-102 that correspond to the desired time.

  • Page 85: Beep After Good Decode

    Parameter Menus Beep After Good Decode Scan the appropriate bar code below to select whether or not the scanner beeps after a good decode. If DO NOT BEEP is selected, the beeper still operates during parameter menu scanning and indicates error conditions. BEEP AFTER GOOD DECODE DO NOT BEEP AFTER GOOD DECODE 5-25...

  • Page 86: Transmit "No Read" Message

    Scan the appropriate bar code below to select whether or not a “No Read” message is transmitted. When enabled, if a symbol does not decode, “NR” is transmitted. When disabled, if a symbol does not read, nothing is sent to the host.

  • Page 87: Linear Code Type Security Level

    Parameter Menus Linear Code Type Security Level The scanner offers four levels of decode security for linear code types (e.g., Code 39, Interleaved 2 of 5). Higher security levels are selected for decreasing levels of bar code quality. As security levels increase, the scanner’s aggressiveness decreases. Select the security level appropriate for your bar code quality.

  • Page 88: Linear Security Level 3

    P 370/470 RF Scanner Product Reference Guide Linear Code Type Security Level (Continued) Linear Security Level 3 Code types other than the following must be successfully read twice before being decoded. The following codes must be read three times: Code Type Length MSI Plessey 4 or less...

  • Page 89: Bi-Directional Redundancy

    Parameter Menus Bi-directional Redundancy This parameter is only valid when a Linear Code Type Security Level (see page 5-27) is enabled. When this parameter is enabled, a bar code must be successfully scanned in both directions (forward and reverse) before being decoded. ENABLE BI-DIRECTIONAL REDUNDANCY DISABLE BI-DIRECTIONAL REDUNDANCY 5-29...

  • Page 90: Enable/Disable Upc-E/Upc-A/Upc-E1

    P 370/470 RF Scanner Product Reference Guide Enable/Disable UPC-E/UPC-A/UPC-E1 Scan the appropriate bar code below to enable or disable UPC-E or UPC-A. DISABLE UPC-E ENABLE UPC-E ENABLE UPC-A DISABLE UPC-A DISABLE UPC-E1 ENABLE UPC-E1 5-30...

  • Page 91: Enable/Disable Ean-8/Ean-13

    Parameter Menus Enable/Disable EAN-8/EAN-13 Scan the appropriate bar code below to enable or disable EAN-8 or EAN-13. ENABLE EAN-8 DISABLE EAN-8 ENABLE EAN-13 DISABLE EAN-13 5-31...

  • Page 92: Enable/Disable Bookland Ean

    P 370/470 RF Scanner Product Reference Guide Enable/Disable Bookland EAN Scan the appropriate bar code below to enable or disable Bookland EAN. ENABLE BOOKLAND EAN DISABLE BOOKLAND EAN 5-32...

  • Page 93: Decode Upc/Ean Supplementals

    Parameter Menus Decode UPC/EAN Supplementals Supplementals are characters (either 2 or 5) that are added on according to specific code format conventions (e.g., UPC A+2, UPC E+2, EAN 8+2). Three options are available. If Decode UPC/EAN with supplementals is selected, UPC/EAN symbols without supplemental characters are not decoded.

  • Page 94: Decode Upc/Ean Supplemental Redundancy

    With Autodiscriminate UPC/EAN Supplementals selected, this option adjusts the number of times a symbol without supplementals is decoded before transmission. The range is from two to 20 times. Five or above is recommended when decoding a mix of UPC/EAN symbols with and without supplementals, and the autodiscriminate option is selected.

  • Page 95: Transmit Upc-A/Upc-E/Upc-E1 Check Digit

    Parameter Menus Transmit UPC-A/UPC-E/UPC-E1 Check Digit Scan the appropriate bar code below to transmit the symbol with or without the UPC-A, UPC-E, or UPC-E1 check digit. TRANSMIT UPC-A CHECK DIGIT DO NOT TRANSMIT UPC-A CHECK DIGIT TRANSMIT UPC-E CHECK DIGIT...

  • Page 96: Upc-A Preamble

    Three options are given for lead-in characters for UPC-A symbols transmitted to the host device: transmit system character only, transmit system character and country code (“0” for USA), and no preamble transmitted. The lead-in characters are considered part of the symbol. NO PREAMBLE (<DATA>)

  • Page 97: Upc-E Preamble

    Three options are given for lead-in characters for UPC-E symbols transmitted to the host device: Transmit system character only, transmit system character and country code (“0” for USA), and no preamble transmitted. The lead-in characters are considered part of the symbol. NO PREAMBLE (<DATA>)

  • Page 98: Upc-E1 Preamble

    Three options are given for lead-in characters for UPC-E1 symbols transmitted to the host device: Transmit system character only, transmit system character and country code (“0” for USA), and no preamble transmitted. The lead-in characters are considered part of the symbol. NO PREAMBLE (<DATA>)

  • Page 99: Convert Upc-E To Upc-A

    Parameter Menus Convert UPC-E to UPC-A This parameter converts UPC-E (zero suppressed) decoded data to UPC-A format before transmission. After conversion, data follows UPC-A format and is affected by UPC-A programming selections (e.g., Preamble, Check Digit). Scanning DO NOT CONVERT UPC-E TO UPC-A allows you to transmit UPC-E (zero suppressed) decoded data.

  • Page 100: Convert Upc-E1 To Upc-A

    P 370/470 RF Scanner Product Reference Guide Convert UPC-E1 to UPC-A This parameter converts UPC-E1 decoded data to UPC-A format before transmission. After conversion, data follows UPC-A format and is affected by UPC-A programming selections (e.g., Preamble, Check Digit). Scanning DO NOT CONVERT UPC-E1 TO UPC-A allows you to transmit UPC-E1 decoded data.

  • Page 101: Ean Zero Extend

    Parameter Menus EAN Zero Extend If this parameter is enabled, five leading zeros are added to decoded EAN-8 symbols to make them compatible in format to EAN-13 symbols. Disabling this parameter returns EAN-8 symbols to their normal format. ENABLE EAN ZERO EXTEND DISABLE EAN ZERO EXTEND 5-41...

  • Page 102: Convert Ean-8 To Ean-13 Type

    When EAN Zero Extend is enabled, this parameter gives you the option of labeling the extended symbol as either an EAN-13 bar code, or an EAN-8 bar code. When EAN Zero Extend is disabled, this parameter has no effect on bar code data.

  • Page 103: Upc/Ean Security Level

    Parameter Menus UPC/EAN Security Level The scanner offers four levels of decode security for UPC/EAN bar codes. Increasing levels of security are provided for decreasing levels of bar code quality. There is an inverse relationship between security and scanner aggressiveness, so be sure to choose only that level of security necessary for any given application.

  • Page 104: Upc/Ean Security Level 2

    P 370/470 RF Scanner Product Reference Guide UPC/EAN Security Level (Continued) UPC/EAN Security Level 2 If you are experiencing mis-decodes of poorly printed bar codes, and the mis-decodes are not limited to characters 1, 2, 7, and 8, select this security level. UPC/EAN SECURITY LEVEL 2 UPC/EAN Security Level 3 If you have tried Security Level 2, and are still experiencing misdecodes, select this security...

  • Page 105: Upc/Ean Coupon Code

    Parameter Menus UPC/EAN Coupon Code When this parameter is enabled, the scanner decodes UPC-A, UPC-A with 2 supplemental characters, UPC-A with 5 supplemental characters, and UPC-A/EAN128 bar codes. AUTODISCRIMINATE UPC/EAN SUPPLEMENTALS on page 5-33 must be enabled. ENABLE UPC/EAN COUPON CODE DISABLE UPC/EAN COUPON CODE 5-45...

  • Page 106: Enable/Disable Code 128

    P 370/470 RF Scanner Product Reference Guide Enable/Disable Code 128 Scan the appropriate bar code below to enable or disable Code 128. ENABLE CODE 128 DISABLE CODE 128 Note: The “|” character and the NULL character cannot be embedded in the barcode to be scanned when using Code 128.

  • Page 107: Enable/Disable Ucc/Ean-128

    Parameter Menus Enable/Disable UCC/EAN-128 Scan the appropriate bar code below to enable or disable UCC/EAN-128. (See Appendix A, Bar Code Information for details on UCC/EAN-128.) ENABLE UCC/EAN-128 DISABLE UCC/EAN-128 Lengths for Code 128 No length setting is required for Code 128. The default setting is Any Length. 5-47...

  • Page 108: Enable/Disable Code 39

    P 370/470 RF Scanner Product Reference Guide Enable/Disable Code 39 Scan the appropriate bar code below to enable or disable Code 39. ENABLE CODE 39 DISABLE CODE 39 5-48...

  • Page 109: Enable/Disable Trioptic Code 39

    Parameter Menus Enable/Disable Trioptic Code 39 Trioptic Code 39 symbols always contain six characters. Trioptic Code 39 and Code 39 Full ASCII cannot be enabled simultaneously. If you get an error beep when enabling Trioptic Code 39, disable Code 39 Full ASCII and try again. To enable or disable Trioptic Code 39, scan the appropriate bar code below.

  • Page 110: Set Lengths For Code 39

    P 370/470 RF Scanner Product Reference Guide Set Lengths for Code 39 Lengths for Code 39 may be set for any length, one or two discrete lengths, or lengths within a specific range. The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains.

  • Page 111: Set Lengths For Code 39

    Parameter Menus Set Lengths for Code 39 (Continued) Length Within Range - This option allows you to decode a code type within a specified range. For example to decode Code 39 symbols containing between 4 and 12 characters, first scan Code 39 Length Within Range. Then scan 0, 4, 1 and 2 (single digit numbers must always be preceded by a leading zero).

  • Page 112: Code 39 Check Digit Verification

    P 370/470 RF Scanner Product Reference Guide Code 39 Check Digit Verification When enabled, this parameter checks the integrity of a Code 39 symbol to ensure it complies with specified algorithms. Only those Code 39 symbols which include a modulo 43 check digit are decoded when this parameter is enabled.

  • Page 113: Transmit Code 39 Check Digit

    Parameter Menus Transmit Code 39 Check Digit Scan the appropriate bar code below to transmit the data with or without the check digit. TRANSMIT CODE 39 CHECK DIGIT (ENABLE) DO NOT TRANSMIT CODE 39 CHECK DIGIT (DISABLE) 5-53...

  • Page 114: Enable/Disable Code 39 Full Ascii

    P 370/470 RF Scanner Product Reference Guide Enable/Disable Code 39 Full ASCII Scan the appropriate bar code below to enable or disable Code 39 Full ASCII. When enabled, the ASCII character set assigns a code to letters, punctuation marks, numerals, and most control keystrokes on the keyboard. The first 32 codes are non-printable and are assigned to keyboard control characters such as BACKSPACE and RETURN.

  • Page 115: Convert Code 39 To Code 32

    Parameter Menus Convert Code 39 to Code 32 Scan the appropriate bar code below to enable or disable converting Code 39 to Code 32. Note: Code 39 must be enabled in order for this parameter to function. CONVERT CODE 39 TO CODE 32 (ENABLE) DO NOT CONVERT CODE 39 TO CODE 32 (DISABLE)

  • Page 116: Code 32 Prefix

    P 370/470 RF Scanner Product Reference Guide Code 32 Prefix Scan the appropriate bar code below to enable or disable the prefix character “A” to all Code 32 bar codes. Note: Convert Code 39 to Code 32 must be enabled for this parameter to function.

  • Page 117: Enable/Disable Code 93

    Parameter Menus Enable/Disable Code 93 Scan the appropriate bar code below to enable or disable Code 93. ENABLE CODE 93 DISABLE CODE 93 5-57...

  • Page 118: Set Lengths For Code 93

    P 370/470 RF Scanner Product Reference Guide Set Lengths for Code 93 Lengths for Code 93 may be set for any length, one or two discrete lengths, or lengths within a specific range. The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains.

  • Page 119: Set Lengths For Code 93

    Parameter Menus Set Lengths for Code 93 (Continued) Length Within Range - This option allows you to decode a code type within a specified range. For example to decode Code 93 symbols containing between 4 and 12 characters, first scan Code 93 Length Within Range. Then scan 0, 4, 1 and 2 (single digit numbers must always be preceded by a leading zero).

  • Page 120: Enable/Disable Interleaved 2 Of 5

    P 370/470 RF Scanner Product Reference Guide Enable/Disable Interleaved 2 of 5 Scan the appropriate bar code below to enable or disable Interleaved 2 of 5. ENABLE INTERLEAVED 2 OF 5 DISABLE INTERLEAVED 2 OF 5 5-60...

  • Page 121: Set Lengths For Interleaved 2 Of 5

    Parameter Menus Set Lengths for Interleaved 2 of 5 Lengths for I 2 of 5 may be set for any length, one or two discrete lengths, or lengths within a specific range. The length of a code refers to the number of characters (i.e., human readable characters) the code contains and includes check digits.

  • Page 122: Set Lengths For Interleaved 2 Of 5

    P 370/470 RF Scanner Product Reference Guide Set Lengths for Interleaved 2 of 5 (Continued) Length Within Range - This option allows you to decode a code type within a specified range. For example to decode I 2 of 5 symbols containing between 4 and 12 characters, first scan I 2 of 5 Length Within Range.

  • Page 123: I 2 Of 5 Check Digit Verification

    Parameter Menus I 2 of 5 Check Digit Verification When enabled, this parameter checks the integrity of an I 2 of 5 symbol to ensure it complies with a specified algorithm, either USS (Uniform Symbology Specification), or OPCC (Optical Product Code Council).

  • Page 124: Transmit I 2 Of 5 Check Digit

    P 370/470 RF Scanner Product Reference Guide Transmit I 2 of 5 Check Digit Scan the appropriate bar code below to transmit the data with or without the check digit. TRANSMIT I 2 of 5 CHECK DIGIT (ENABLE) DO NOT TRANSMIT I 2 of 5 CHECK DIGIT (DISABLE) 5-64...

  • Page 125: Convert I 2 Of 5 To Ean-13

    Parameter Menus Convert I 2 of 5 to EAN-13 This parameter converts a 14 character I 2 of 5 code into EAN-13, and transmits to the host as EAN-13. In order to accomplish this, the I 2 of 5 code must be enabled, one length must be set to 14, and the code must have a leading zero and a valid EAN-13 check digit.

  • Page 126: Enable/Disable Discrete 2 Of 5

    P 370/470 RF Scanner Product Reference Guide Enable/Disable Discrete 2 of 5 Scan the appropriate bar code below to enable or disable Discrete 2 of 5. ENABLE DISCRETE 2 OF 5 DISABLE DISCRETE 2 OF 5 5-66...

  • Page 127: Set Lengths For Discrete 2 Of 5

    Parameter Menus Set Lengths for Discrete 2 of 5 Lengths for D 2 of 5 may be set for any length, one or two discrete lengths, or lengths within a specific range. The length of a code refers to the number of characters (i.e., human readable characters) the code contains, and includes check digits.

  • Page 128: Set Lengths For Discrete 2 Of 5

    P 370/470 RF Scanner Product Reference Guide Set Lengths for Discrete 2 of 5 (Continued) Length Within Range - This option allows you to decode a code type within a specified range. For example to decode D 2 of 5 symbols containing between 4 and 12 characters, first scan D 2 of 5 Length Within Range.

  • Page 129: Enable/Disable Codabar

    Parameter Menus Enable/Disable Codabar Scan the appropriate bar code below to enable or disable Codabar. ENABLE CODABAR DISABLE CODABAR 5-69...

  • Page 130: Set Lengths For Codabar

    P 370/470 RF Scanner Product Reference Guide Set Lengths for Codabar Lengths for Codabar may be set for any length, one or two discrete lengths, or lengths within a specific range. The length of a code refers to the number of characters (i.e., human readable characters) the code contains.
  • Page 131 Parameter Menus Set Lengths for Codabar (Continued) Length Within Range - This option allows you to decode a code type within a specified range. For example to decode Codabar symbols containing between 4 and 12 characters, first scan Codabar Length Within Range. Then scan 0, 4, 1 and 2 (single digit numbers must always be preceded by a leading zero).

  • Page 132: Clsi Editing

    If enabled, this parameter strips the start and stop characters and inserts a space after the first, fifth, and tenth characters of a 14-character Codabar symbol. Note: Symbol length does not include start and stop characters. ENABLE CLSI EDITING DISABLE CLSI EDITING...

  • Page 133: Notis Editing

    Parameter Menus NOTIS Editing If enabled, this parameter strips the start and stop characters from a decoded Codabar symbol. ENABLE NOTIS EDITING DISABLE NOTIS EDITING 5-73...

  • Page 134: Enable/Disable Msi Plessey

    P 370/470 RF Scanner Product Reference Guide Enable/Disable MSI Plessey Scan the appropriate bar code below to enable or disable MSI Plessey. ENABLE MSI PLESSEY DISABLE MSI PLESSEY 5-74...

  • Page 135: Set Lengths For Msi Plessey

    Parameter Menus Set Lengths for MSI Plessey Lengths for MSI Plessey may be set for any length, one or two discrete lengths, or lengths within a specific range. The length of a code refers to the number of characters (i.e., human readable characters) the code contains, and includes check digits.
  • Page 136 P 370/470 RF Scanner Product Reference Guide Set Lengths for MSI Plessey (Continued) Length Within Range - This option allows you to decode a code type within a specified range. For example to decode MSI Plessey symbols containing between 4 and 12 characters, first scan MSI Plessey Length Within Range.

  • Page 137: Msi Plessey Check Digits

    Parameter Menus MSI Plessey Check Digits These check digits at the end of the bar code verify the integrity of the data. At least one check digit is always required. Check digits are not automatically transmitted with the data. ONE MSI PLESSEY CHECK DIGIT TWO MSI PLESSEY CHECK DIGITS 5-77...

  • Page 138: Transmit Msi Plessey Check Digit

    P 370/470 RF Scanner Product Reference Guide Transmit MSI Plessey Check Digit Scan the appropriate bar code below to transmit the data with or without the check digit. TRANSMIT MSI PLESSEY CHECK DIGIT (ENABLE) DO NOT TRANSMIT MSI PLESSEY CHECK DIGIT (DISABLE) 5-78...

  • Page 139: Msi Plessey Check Digit Algorithm

    Parameter Menus MSI Plessey Check Digit Algorithm When the two MSI Plessey check digits option is selected, an additional verification is required to ensure integrity. Either of the two following algorithms may be selected. MOD 10/MOD 11 MOD 10/MOD 10 5-79...

  • Page 140: Transmit Code Id Character

    The code ID character precedes the decoded symbol. The user may select no code ID character, a Symbol Code ID character, or an AIM Code ID character. The Symbol Code ID characters are listed below; see Appendix A, Bar Code Information for AIM Identifiers.
  • Page 141 Parameter Menus Transmit Code ID Character (Continued) SYMBOL CODE ID CHARACTER AIM CODE ID CHARACTER NONE 5-81...

  • Page 142: Pause Duration

    P 370/470 RF Scanner Product Reference Guide Pause Duration This parameter allows a pause to be inserted at any point in the data transmission. Pauses are set by scanning the bar code below followed by a two digit number (i.e. two bar codes), and are measured in 1/10 second intervals.

  • Page 143: Rs-232C Parameters

    Parameter Menus RS-232C Parameters Baud Rate Baud rate is the number of bits of data transmitted per second. The scanner's baud rate setting should match the data rate setting of the host device. If not, data may not reach the host device or may reach it in distorted form.

  • Page 144: Baud Rate (Continued)

    P 370/470 RF Scanner Product Reference Guide Baud Rate (Continued) BAUD RATE 4800 BAUD RATE 9600 BAUD RATE 19,200 BAUD RATE 38,400 5-84...

  • Page 145: Parity

    Parameter Menus Parity A parity check bit is the most significant bit of each ASCII coded character. Select the parity type according to host device requirements. If you select ODD parity, the parity bit has a value 0 or 1, based on data, to ensure that an odd number of 1 bits are contained in the coded character.

  • Page 146: Parity (Continued)

    P 370/470 RF Scanner Product Reference Guide Parity (Continued) Select MARK parity and the parity bit is always 1. MARK Select SPACE parity and the parity bit is always 0. SPACE If no parity is required, select NONE. NONE 5-86...

  • Page 147: Check Receive Errors

    Parameter Menus Check Receive Errors Select whether or not the parity, framing, and overrun of received characters are checked. The type of parity used is selectable through the PARITY parameter. CHECK FOR RECEIVED ERRORS DO NOT CHECK FOR RECEIVED ERRORS 5-87...

  • Page 148: Hardware Handshaking

    P 370/470 RF Scanner Product Reference Guide Hardware Handshaking The data interface consists of an RS-232C port. The port has been designed to operate either with or without the hardware handshaking lines, RTS, Request to Send, and CTS, Clear to Send.

  • Page 149: Hardware Handshaking (Continued)

    Parameter Menus Hardware Handshaking (Continued) Scan the bar code below if no Hardware Handshaking is desired. NONE Scan the bar code below to select Standard RTS/CTS Hardware Handshaking. STANDARD RTS/CTS When RTS/CTS Option 1 is selected, the cradle asserts RTS before transmitting and ignores the state of CTS.

  • Page 150: Hardware Handshaking (Continued)

    P 370/470 RF Scanner Product Reference Guide Hardware Handshaking (Continued) When Option 2 is selected, RTS is always high or low (user-programmed logic level). However, the scanner waits for CTS to be asserted before transmitting data. If CTS is not asserted within two seconds (default), the scanner issues an error indication and discards the data.

  • Page 151: Software Handshaking (Continued)

    Parameter Menus Software Handshaking (Continued) ACK/NAK When this option is selected, after transmitting data, the cradle expects either an ACK, Acknowledge, or NAK, Negative Acknowledge, response from the host. Whenever a NAK is received, the cradle transmits the same data again and waits for either an ACK or NAK. After three unsuccessful attempts to send data when NAKs are received, the cradle issues an error indication and discards the data.

  • Page 152: Software Handshaking (Continued)

    P 370/470 RF Scanner Product Reference Guide Software Handshaking (Continued) XON/XOFF An XOFF, Transmit Off, character turns the scanner transmission off until the scanner receives an XON, Transmit On, character. There are two situations for XON/XOFF: XOFF is received before the scanner has data to send. When the scanner has data to send, it then waits for an XON character before transmission.

  • Page 153: Rts Line State

    Parameter Menus RTS Line State Scan the appropriate bar code below to set the idle state of the Serial Host RTS line. Choose LOW RTS line state or HIGH RTS line state. HOST: LOW RTS HOST: HIGH RTS 5-93...

  • Page 154: Stop Bit Select

    P 370/470 RF Scanner Product Reference Guide Stop Bit Select The stop bit(s) at the end of each transmitted character marks the end of transmission of one character and prepares the receiving device for the next character in the serial data stream. The number of stop bits (one or two) selected depends on the number the receiving terminal is programmed to accommodate.

  • Page 155: Intercharacter Delay

    Parameter Menus Intercharacter Delay Select the intercharacter delay option matching host requirements. The intercharacter delay gives the host system time to service its receiver and perform other tasks between characters. The delay period can range from no delay to 99 ms in 1 ms increments (if you are using a cradle and RTS/CTS handshaking, the delay period can range from 5 ms to 99 ms).
  • Page 156 P 370/470 RF Scanner Product Reference Guide BAUD RATE 1200 BAUD RATE 2400 5-96...

  • Page 157: Mcl-Net Baud Rate (Continued)

    Parameter Menus MCL-Net Baud Rate (Continued) BAUD RATE 4800 BAUD RATE 9600 BAUD RATE 19200 BAUD RATE 38400 5-97...

  • Page 158: Mcl-Net Hex Addressing Mode

    P 370/470 RF Scanner Product Reference Guide MCL-Net Hex Addressing Mode Scan the appropriate bar code below to set the MCL-Net Hex addressing mode. The default mode is Disabled. MCL-NET HEX ADDRESSING DISABLED MCL-NET HEX ADDRESSING ENABLED 5-98...

  • Page 159: Scanner Address

    Parameter Menus Scanner Address Scan the following barcode, followed by 3 digits from the numeric barcode section (starting on page 5-102), to define the (decimal) address of the scanner in the range 001 to 254. SCANNER ADDRESS MCL-Net Transmit Retries Scan the following barcode, followed by 2 digits from the numeric barcode section (starting on page 5-102), to define the number of retries in the range 1 to 10.

  • Page 160: Mcl Pos Host

    P 370/470 RF Scanner Product Reference Guide MCL POS Host Scan the appropriate barcode below to choose MCL-Net or Other as the host to be used by the default application during POS mode. Choosing MCL-Net enables the scanner to communicate with a host running MCL-Link. Choosing Other selects a standard RS-232 or Synapse host, as defined by the system installation.

  • Page 161: Scanner Decode Beep Type

    Parameter Menus Scanner Decode Beep Type Select the type of beep for the scanner. This parameter is useful when two or more systems are installed in proximity of each other. Unique patterns can be set up to distinguish each system’s receipt of bar code data. BEEP TYPE 1 BEEP TYPE 2 BEEP TYPE 3...

  • Page 162: Numeric Bar Codes

    P 370/470 RF Scanner Product Reference Guide Numeric Bar Codes For parameters requiring specific numeric values, scan the appropriately numbered bar code(s). 5-102...
  • Page 163 Parameter Menus Numeric Bar Codes (Continued) 5-103...

  • Page 164: Cancel

    P 370/470 RF Scanner Product Reference Guide Numeric Bar Codes (Continued) Cancel If you make an error, or wish to change your selection, scan the bar code below. CANCEL 5-104...

  • Page 165: Appendix A Bar Code Information

    UCC/EAN-128 symbols are distinguished by a leading FNC 1 character as the first or second character in the symbol. Other FNC 1 characters are used to delineate fields. When EAN-128 symbols are read, they are transmitted after special formatting strips off the leading FNC 1 character and replaces other FNC 1 characters with the ASCII 29 GS control character.
  • Page 166 P 370/470 RF Scanner Product Reference Guide Table A-1. Reading Standard Code128 & UCC/EAN 128 Standard Code UCC/EAN- Effect and Example Disable Disable No Code 128 symbols can be read. Disable Enable Read only symbols with leading FNC 1. Examples: FNC1 FNC1 ABCD...

  • Page 167: Aim Code Identifiers

    Bar Code Information AIM Code Identifiers Each AIM Code Identifier contains the three-character string ]cm where: = Flag Character (ASCII 93) = Code Character (see Table A-2) = Modifier Character (see Table A-3) Table A-2. Code Characters Code Character Code Type Code 39 Code 128/EAN-128 UPC/EAN...
  • Page 168 No option specified at this time. Always transmit 0. Example: A Trioptic bar code 412356 is transmitted as ]X0412356 Code 128 Standard data packet, no Function code 1 in first symbol position. Function code 1 in first symbol character position.
  • Page 169 Bar Code Information Table A-3. Modifier Characters (Cont’d) Code Type Option Value Option Codabar No check digit processing. Reader has checked check digit. Reader has stripped check digit before transmission. Example: A Codabar bar code without check digit, 4123, is transmitted as ]F04123 Code 93 No options specified at this time.
  • Page 170 P 370/470 RF Scanner Product Reference Guide According to AIM standards, a UPC with supplemental bar code is transmitted in one of the following formats: ]E0 (UPC chars) (terminator) ]E2 (supplemental) (terminator) or ]E2 (supplemental) (terminator) ]E0 (UPC chars) (terminator) In the scanner, however, the format is changed to: ]E0 (UPC chars) ]E2 (supplemental) Therefore, a UPC with two supplemental characters, 01234567890510, is transmitted to the...
  • Page 171 Bar Code Information Table A-4. ASCII Character Set ASCII Full ASCII Keystroke ASCII Full ASCII Keystroke Code 39 Code 39 Value Value Encode Char. Encode Char 1000 CTRL 2 1024 CTRL X 1001 CTRL A 1025 CTRL Y 1002 CTRL B 1026 CTRL Z 1003...
  • Page 172 P 370/470 RF Scanner Product Reference Guide Table A-4. ASCII Character Set (Cont’d) ASCII Full ASCII Keystroke ASCII Full ASCII Keystroke Code 39 Code 39 Value Value Encode Char. Encode Char 1048 1073 1049 1074 1050 1075 1051 1076 1052 1077 1053 1078...
  • Page 173 Bar Code Information Table A-4. ASCII Character Set (Cont’d) ASCII Full ASCII Keystroke ASCII Full ASCII Keystroke Code 39 Code 39 Value Value Encode Char. Encode Char 1098 1113 1099 1114 1100 1115 1101 1116 1102 1117 1103 1118 1104 1119 1105 1120...
  • Page 174 P 370/470 RF Scanner Product Reference Guide Table A-4. ASCII Character Set (Cont’d) ALT Keys Keystroke ALT Keys Keystroke ALT Keys Keystroke 2064 ALT 2 2075 ALT K 2086 ALT V 2065 ALT A 2076 ALT L 2087 ALT W 2066 ALT B 2077...
  • Page 175 Bar Code Information Table A-4. ASCII Character Set (Cont’d) PF Keys Keystroke PF Keys Keystroke PF Keys Keystroke 4001 PF 1 4009 PF 9 4017 PF 17 4002 PF 2 4010 PF 10 4018 PF 18 4003 PF 3 4011 PF 11 4019 PF 19...
  • Page 176 P 370/470 RF Scanner Product Reference Guide Table A-4. ASCII Character Set (Cont’d) Numeric Keystroke Numeric Keystroke Numeric Keystroke Keypad Keypad Keypad 6042 6049 6056 6043 6050 6057 6044 Undefined 6051 6058 Enter 6045 6062 6059 Num Lock 6046 6063 6060 6047 6064...

  • Page 177: Appendix B Automatic Project Download

    Appendix B Automatic Project Download The Phaser P 370/470 RF scanner is shipped from the factory with a pre-installed default application. This application allows the scanner to be used “out of the box” for users who choose to do so. However, most users will prefer to load their own application into the scanner, so the default application implements an “Automatic Project Download”...
  • Page 178 P 370/470 RF Scanner Product Reference Guide Note that designer always appends the .prj suffix to the directories it creates to store project files. The PROJECT.CMD file will be automatically generated by the MCL-Designer application.

  • Page 179: Index

    UPC-E/UPC-A/UPC-E1 5-30 scan the entire symbol ... . . 3-4 host type ..... . 5-14 ambient light immunity I 2 of 5 check digit verification .
  • Page 180 P 370/470 RF Scanner Product Reference Guide UPC-A Preamble ....5-36 UPC-E Preamble ....5-37 ENABLE UPC-E1 .
  • Page 181 ..... . 5-5 symbol support center ....x pitch .
  • Page 182 P 370/470 RF Scanner Product Reference Guide Index-4...

  • Page 183: Tell Us What You Think

    We’d like to know what you think about this Manual. Please take a moment to fill out this questionnaire and fax this form to: (631) 738-3318, or mail Symbol Technologies, Inc. One Symbol Plaza M/S B-4 Holtsville, NY 11742-1300 Attn: Technical Publications Manager IMPORTANT: If you need product support, please call the appropriate cus- tomer support number provided.

Table of Contents
