Pressure
Standard differential pressure, Working pressure differential
Standard differential pressure (kPa)
H2 Working pressure differential (kPa)
Max. working pressure (kPa)
Standard differential pressure (kPa)
HE Working pressure differential (kPa)
Max. working pressure (kPa)
Display, integrating functions
Display range
Flow rate
display
Display resolution
Display range
Integrating
Display resolution
functions *7
Pulse output rate
*1: Flow rate converted to volumetric flow rate at 20°C, 1 barometric pressure (101 kPa). Full scale stands for max. scale flow rate in the flow rate range.
*2: Use dry gas which does not contain corrosive elements such as chlorine, sulfur or acids, and which is clean and does not contain dust or oil mist.
*3: Standard differential pressure is the differential pressure when this product is calibrated. (Secondary side released to atmosphere)
*4: Working pressure differential is the differential pressure required for normal operation of this product. Note that the values depend on the flow rate range and
applicable fluids. The min. value of the working pressure differential is the differential pressure required for the full scale flow rate to flow when secondary side
is released to atmosphere. The max. working pressure (max. value of working pressure differential) is the max. value of primary side pressure. If more pressure
is applied, control may become unstable, or the max. flow rate may not be controllable.
*5: Ensure that the current supply capacity per IO-Link master port is sufficient.
*6: This product's protection circuit is effective only for specific misconnections. It does not provide protection for all misconnections.
*7: The accumulated flow is a reference value. It is reset when the power is turned OFF.
*8: The valve inside this product cannot be used as a stop valve requiring zero leakage. Slight leakage is allowed for in the specifications.
0002 0005
20
10 to 50 30 to 80
50
50
20 to 100 50 to 150
100
0002 0005
0.00 to 2.00 L/min 0.00 to 5.00 L/min
0.01 L/min 0.01 L/min
9999.99 L 9999.99 L
0.01 L 0.01 L
0.02 L 0.05 L
Flow rate range *1
0010
50 50
30 to 80
80 80
100 100
50 to 150
150 150
Flow rate range *1
0010
0.0 to 10.0 L/min
0.1 L/min
99999.9 L
0.1 L
0.1 L
FCM
Series
Specifications
0020
50
30 to 80
80
100
50 to 150
150
0020
0.0 to 20.0 L/min
0.1 L/min
99999.9 L
0.1 L
0.2 L
4
