CKD IO-Link FCM Series Manual page 14

FCM
Series
Dedicated bracket (floor mounted)
FCM-LB1
Discrete model No.:
Cable optional dimensions
●
Cable option (M12 straight (female), M12 straight (male))
FCM-MS3
Discrete model No.:
●
Cable option (M12 L type (female), M12 straight (male))
FCM-ML3
Discrete model No.:
●
Cable option (M12 one side straight (female))
FCM-MM3
Discrete model No.:
9
65
30
4-6
3000
3000
3000
Cable color Applications
Brown L + (24 DC)
White N.C. *
Blue L-(GND)
Black C(IO-Link)
5
Material : Steel
1
Weight : 28 g
* Insulate wires so that they do not contact other wires.
