CKD IO-Link FCM Series Manual page 2

Supports the IoT generation!
Flow rate controller
predictive maintenance functions
Stainless steel body
[Applicable fluids/flow rates]
AIR N
2
0.015 to 50 L/min
Ar
0.015 to 50 L/min
O 13A CH C H
2 4 3 8
0.015 to 10 L/min
H He
2
0.06 to 20 L/min
Weight: Approx. 480 g
Rectifying mechanism reduces
pressure loss and improves
reproducibility
Introducing the IO-Link model
IO-Link is a digital communication standard for sensors/actuators at factory sites. (IEC 61131-9)
Unlike analog communication, it enables the transmission of parameters and event data.
Cloud
Plant
PLC
Housing
identification
IO-Link
parameter
Master
change
I/O
Features of IO-Link
Digital signal
Parameter remote control
Ethernet
Housing identification
Data storage
Continuous
monitoring alarm
notification
Error notification
Connection to fieldbus
equipped with
Equipped with high-speed
response micro-machined
sensor chip
Constant monitoring via digital data is possible.
Parameters can be set and changed via the
network, enabling remote equipment operation.
Models, serial numbers, etc., can be confirmed
on the network.
The settings can be copied from the master
(scanner), making parameter reconfiguration
after maintenance obsolete.
Device failure and disconnection can be
confirmed.
It can also be converted to Ethernet networks
and connected, enabling devices to be IoT-ready.
Resin body
[Applicable fluids/
flow rates]
AIR N
2
0.015 to 100 L/min
Weight: Approx. 200 g
