CKD IO-Link FCM Series Manual page 12

FCM
Series
Dimensions
□
Model No.: FCM- -H6C/H8C
Port size: Push-in (ø6) or (ø8)
16
30
□
Model No.: FCM- -8AC/UFC
Port size: Rc1/4 or 9/16-18UNF
16
30
9/16-18UNF
11.5
Mesh filter
15.25
7
□
FCM-ML3 (Optional)
Note: The cable draw direction is fixed in the orientation shown in the figure.
(31)
(41)
M12, 4-pin connector
FCM-MS3, MM3
(Optional)
11
□
FCM-ML3 (Optional)
Note: The cable draw direction is fixed in the orientation shown in the figure.
(31)
(41)
M12, 4-pin connector
FCM-MS3, MM3
(Optional)
11
2.5
9/16-18UNF
Effective thread depth 11.5
□ □ □
For FCM- - CR , display direction is reversed.
70
Port size
(A) 2-ø6 push-in fitting or
2-ø8 push-in fitting
30
Model No.
FCM-
FCM-
2-M3 depth 5
□ □ □
For FCM- - CR , display direction is reversed.
70
30
2-M3 depth 5
Dimension
Fitting
(A)
□ □
-H6C ø6 push-in 84
□ □
-H8C ø8 push-in 85
Port size
2-Rc1/4 or
2-9/16-18UNF
