Delta C2000 Plus Series User Manual page 1157

Chapter 16 PLC Function ApplicationsC2000 Plus
API
TAN
132
D
Bit device
X Y M
S
D
Notes on operand usage:
Please refer to the function specifications table for each device in
series for the scope of device usage






The following figure displays the relationship between the arc and TAN results:

X0
P
Word device
K H KnX KnY KnM
* *
S: the designated source value. D: the TAN value result.
The source designated by S can be given as radians or an angle; this is decided by
flag M1018.
When M1018=Off, the operation is in radians mode, where the radians (RAD) value
is equal to (angle ×π/180).
When M1018=On, the operation is in the angle mode, where the angular range is
0°≤ angle <360°.
When calculation results yield 0, M1020=On.
The TAN obtained from the source value designated by S is stored in D.
When X0=On, the TAN value of the designated binary floating point number (D1,
D0) in radians (RAD) will be stored in (D11, D10), with the content consisting of a
binary floating point number.
DTAN D0
Binary floating point number TAN operation
16-bit command
－
T C D
*
32-bit command (9 STEP)
*
DTAN
execution type
Flag signal: none
D10
16-94
－ －
Continuous DTANP
execution type
－
Pulse
