Delta C2000 Plus, C2000-HS, C2000-R Manual

System Architecture Overview

Overview of Parallel Control

The parallel solution model is suitable for AC motor drives with the same power of 220kW and above (C2000 Plus, C2000-HS and C2000-R). It addresses the need for capacity expansion in high-power control by enabling internal communication between two AC motor drives (master/ slave) for parallel expansion control. This solution integrates optical fiber communication and system codes to ensure effective parallel control.

In parallel application, due to communication limits, the carrier wave can only reach up to 6 kHz, and the current specification should take 8% derating coefficient (multiplied by 0.92) into consideration when selecting AC motor drive models.

Delta's high-power frequency conversion solutions are divided into two categories:

Solution Description
Non-common DC bus
  • Considers 8% derating coefficient (multiplied by 0.92) when selecting AC motor drives.
  • The length of the powering wire from the mains power supply to the drive must be consistent.
    Non-common DC bus
Common DC bus
  • Due to the different input impedance, circulating current will be generated between some drives. It is necessary to install an AC reactor on the power input side to achieve the effect of proper current distribution.
  • Install each drive as close to each other as possible to reduce the wire length and to reduce the DC side wire inductance as much as possible.
  • When installing with common DC bus, it is recommended to install a fuse on the DC side
    Common DC bus

information NOTE:

  • Ensure that the two parallel-connected drives are the same series models with the same power.
  • The six-phase motor does not require the output reactors.

Model List

Non-common DC bus parallel connection application selection
Table 1-1

AC Motor Drive Reactor
Power (kW) Applicable AC Motor
Drive Models
Rated Current*
(A)
Qty Applicable Reactor Selection Inductance Value
(μH)
405 VFD2200C43x 846 2 DR505LP004P 4.35
VFD2200C43x-HS 846 2 DR505LP004P 4.35
VFD2200C43A-00R 846 2 DR505LP004P 4.35
460 VFD2500C43x 885 2 DR505LP004P 4.35
VFD2500C43A-00R 929 2 DR505LP004P 4.35
515 VFD2800C43x 1012 2 DR616LP004P 3.77
VFD2800C43A-00R 1012 2 DR616LP004P 3.77
580 VFD3150C43x 1133 2 DR616LP004P 3.77
VFD3150C43A-00R 1133 2 DR616LP004P 3.77
653 VFD3550C43x 1256 2 DR770LP003P 2.93
VFD3550C43x-HS 1256 2 DR770LP003P 2.93
VFD3550C43A-00R 1288 2 DR770LP003P 2.93
736 VFD4000C43x 1416 2 DR770LP003P 2.93
828 VFD4500C43x 1593 2 DR930LP002P 2.41
VFD4500C43A-00R 1527 2 DR930LP002P 2.41
920 VFD5000C43x 1711 2 DR930LP002P 2.41
1030 VFD5600C43x 2012 2 DR1212LP002P 1.82

information NOTE: *The rated current is based on the default load mode rated current of each model.

Common DC bus parallel connection application selection

AC Motor Drive Reactor
Power
Table 1-2 (kW)
Applicable AC Motor
Drive Models
Rated Current*
(A)
Qty Applicable Reactor Selection Inductance Value
(μH)
440 VFD2200C43x 920 2 DR505LP004P 4.35
VFD2200C43x-HS 920 2 DR505LP004P 4.35
VFD2200C43A-00R 920 2 DR505LP004P 4.35
500 VFD2500C43x 962 2 DR505LP004P 4.35
VFD2500C43A-00R 1010 2 DR505LP004P 4.35
560 VFD2800C43x 1100 2 DR616LP004P 3.77
VFD2800C43A-00R 1100 2 DR616LP004P 3.77
630 VFD3150C43x 1232 2 DR616LP004P 3.77
VFD3150C43A-00R 1232 2 DR616LP004P 3.77
710 VFD3550C43x 1366 2 DR770LP003P 2.93
VFD3550C43x-HS 1366 2 DR770LP003P 2.93
VFD3550C43A-00R 1400 2 DR770LP003P 2.93
800 VFD4000C43x 1540 2 DR770LP003P 2.93
900 VFD4500C43x 1732 2 DR930LP002P 2.41
VFD4500C43A-00R 1660 2 DR930LP002P 2.41
1000 VFD5000C43x 1860 2 DR930LP002P 2.41
1120 VFD5600C43x 2188 2 DR1212LP002P 1.82

information NOTE: *The rated current is based on the default load mode rated current of each model.

C2000 Plus
Table 1-3

Frame G H
VFD-_ _ _ C_ _ _-21 / -00 2200 2500 2800 3150 3550 4000 4500 5000 5600
*Output Rating Heavy Duty Rated Output Capacity (kVA) 367 383 438 491 544 613 690 741 872
Rated Output Current (A) 460 481 550 616 683 770 866 930 1094
Applicable Motor Output (kW) 220 250 280 315 355 400 450 500 560
Applicable Motor Output (HP) 300 340 375 420 475 530 600 675 750
Overload Capacity 150% of rated output current: 1 minute for every 5 minutes;
180% of rated output current: 3 seconds for every 30 seconds
Max. Output Frequency (Hz) 0.00–599.00
Carrier Frequency (kHz) 2–9 (Default: 4)
Super Heavy Duty Rated Output Capacity (kVA) 295 315 366 438 491 544 544 690 741
Rated Output Current (A) 370 395 460 550 616 683 683 866 930
Applicable Motor Output (kW) 185 200 220 280 315 355 355 450 500
Applicable Motor Output(HP) 250 270 300 375 425 475 475 600 675
Overload Capacity 150% of rated output current: 1 minute for every 5 minutes;
200% of rated output current: 3 seconds for every 30 seconds
Max. Output Frequency (Hz) 0.00–599.00
Carrier Frequency (kHz) 2–9 (Default: 4) 2–9 (Default: 3)
Input Rating Input Current
(A)
Heavy Duty 400 447 494 555 625 770 866 930 1094
Super Heavy Duty 380 390 400 494 555 590 625 866 930
Rated Voltage / Frequency 3-phase AC 380V–480V (-15% – +10%), 50 / 60 Hz
Operating Voltage Range 323–528 VAC
Frequency Tolerance 47–63 Hz
Power Supply
Capacity
(kVA)
Heavy Duty 332.5 371.6 410.7 461.4 519.6 640.1 720.0 773.2 909.5
Super Heavy Duty 315.9 324.2 332.5 410.7 461.4 490.5 519.6 720.0 773.2
Efficiency (%) 98.2
Displacement Power Factor (cosθ) >0.98
Drive Weight (kg) 134 ± 4 228
Cooling Method Fan Cooling
Braking Chopper Optional
DC choke Built-in
EMC Filter Optional
EMC-COP01 Frame G–H (VFDxxxC43A-00): Optional
Frame G–H (VFDxxxC43A-21): Built-in

information NOTE:

  1. *: The default setting is heavy duty mode.
  2. The carrier frequency is default. Increasing the carrier frequency requires a reduction in current. Refer to Section Derating Curve for details inC2000 PlusUser Manual.
  3. The AC motor drive should operate in derating current when its control method is set to FOC Sensorless, TQC+PG, TQC sensorless, PM+PG or PM sensorless. Refer to description of Pr.06-55 inC2000 Plus User Manual for more information.
  4. The rated input current will be affected by not only power transformer and the connection of the reactors on the input side, but also fluctuates with the impedance of power side.
  5. Model VFD4500C43x-xx, VFD5000C43x-xx and VFD5600C43x-xx do not have UL certification.
  6. Rated output capacity is calculated by 460 VAC, it is as a reference for the mains power drive capacity selection.

C2000-HS
Table 1-4

Frame G H
VFD-_ _ _ C43x-HS 2200 3550
Output Rating Normal Duty Rated Output Capacity (kVA) 367 544
Rated Output Current (A) 460 683
Applicable Motor Output (kW) 220 355
Applicable Motor Output (HP) 300 475
Overload Capacity 120% of rated output current: 1 minute for every 5 minutes;
160% of rated output current: 3 seconds for every 30 seconds
Max. Output Frequency (Hz) IM 1000 900
PM 1000 900
Carrier Frequency (kHz) 2–9 (Default: 6)
Input Input Current (A) 400 625
Rated Voltage / Frequency 3 phase 380–480 VAC (-15 – +10%), 50 / 60 Hz
Operating Voltage Range 323–528 VAC
Frequency Tolerance 47–63 Hz
Efficiency (%) > 98 > 98
Displacement Power Factor (cosθ) > 0.98
Drive Weight (kg) 138 228
Cooling Method Fan Cooling
Braking Chopper Optional
DC choke Built-in, EN61000-3-12
EMC Filter Frame D0–H: Optional

NOTE:

  1. The carrier frequency is default. Increasing the carrier frequency requires a reduction in current. Refer to Section Derating Curve in C2000-HS User Manual.
  2. Select the AC motor drive with capacity one grade larger for the impact load application.
  3. The rated input current will be affected by not only Power Transformer and the connection of the reactors on input side, but also fluctuates with the impedance of power side.
  4. For Frame D0 and above, if the last character of the model is A then it is under IP20 protection level, but the wiring terminal is under IP00 protection level.

C2000-R
Table 2-1
Table 1-5

Frame G H
VFD_ _ _ _ C43A-00R 2200 2500 2800 3150 3550 4500
Output Rating Light Duty Rated Output Capacity (kVA) 367 402 438 491 544 660
Rated Output Current (A) 460 505 550 616 700 830
Applicable Motor Output (kW) 220 250 280 315 355 450
Applicable Motor Output (HP) 300 340 375 420 475 600
Overload Capacity 120% of rated output current: 1 minute for every 5 minutes
Max. Output Frequency (Hz) 0.00–599.00
Carrier Frequency (kHz) 2–8 (Default: 4)
Heavy Duty Rated Output Capacity (kVA) 247 270 295 367 383 500
Rated Output Current (A) 310 340 370 460 505 630
Applicable Motor Output (kW) 160 170 185 220 250 315
Applicable Motor Output (HP) 215 230 250 300 340 420
Overload Capacity

1.0 Hz Operation

80% of rated output current: continuous operation

150% of rated output current: 5 seconds for every 10 minutes

2.1 Hz to Max. Operation Frequency

150% of rated output current: 1 minute for every 5 minutes

180% of rated output current: 3 sec. for every 30 seconds

Max. Output Frequency (Hz) 0.00–599.00
Carrier Frequency (kHz) 2–8 (Default: 2)
Input Rating Input Current (A) Light Duty 425 465 510 570 645 765
Heavy Duty 300 370 380 400 481 590
Rated Voltage / Frequency 3-phase AC 380–480V (-15 – +10%), 50 / 60 Hz
Operating Voltage Range 323–528 VAC
Frequency Tolerance 47–63 Hz
Efficiency (%) 97.2 97.2 97.6 97.6 97.6 97.6
Displacement Power Factor (cosθ) >0.98
Drive Weight (kg) 105 ±4 kg 151 ±5 kg 154 ±5 kg 157 ±5 kg 167 ±7 kg
Cooling Method Water Cooling
Braking Chopper Optional
DC choke Built-in
12 Pulse Input Available for Frame H

information NOTE:

  1. The carrier frequency is default. Increasing the carrier frequency requires a reduction in current. Refer to Section Derating Curve inC2000-R User Manual.
  2. The AC motor drive should operate in derating current when its control method is set to FOC Sensorless, TQC+PG, TQC sensorless. PM+PG or PM sensorless. Refer to Pr.06-55 for more information.
  3. Select the AC motor drive with capacity one grade larger for the impact load application.
  4. The rated input current will be affected by not only power transformer and the connection of the reactors on input side, but also fluctuates with the impedance of power side.

Accessories Overview

CMC-FB01 -- Fiber Communication Card
When the AC motor drive is used in parallel control, the master and slave drive communicate with each other through optical fiber. This communication relies on the SPI interface between the MCU and the FPGA optical fiber card. The transmission and reception of signals are completed during each PWM cycle.


Figure 1-1

  • In C2000 series, the optical fiber communication card is installed in Slot 2 by default. If you need to install the communication card in Slot 1, contact Delta for further information.
  • Delta provides two length options for the required fiber optic communication cables.
Model Name Description Fiber Optic Cable Part Number
CBC-FB3M CABLE FOR CMC-FB01 – 3M 3080669500
CBC-FB5M CABLE FOR CMC-FB01 – 5M 3080594300

Table 1-6

  • In the diagram on the left:
    • The left upper corner and the right lower corner are the screw fixing holes.
    • The connector on the bottom of the board are fiber optical communication cables, the black one is RX, and the gray one is TX.

Communication Specifications

Item
Internal Communication
(MCU and FPGA)
External Communication
(between master and slave FPGAs)
Transmission Method SPI synchronous serial (half-duplex) UART asynchronous serial (full duplex)
Error Checking Method CRC and timeout monitoring CRC and timeout monitoring

Table 1-7

Light Meanings

Item SDP3 SDP4 SDP5 SDP6
Light Colors Green Green Green Red
Blinking / Steady Steady Blinking Steady Steady
Representation MCU and FPGA Communication FPGA Power Fiber Card Communication Configuration Data
Description

If the green light is ON, communication is normal.

If it is OFF, check the SPI pins for connection issues or configuration problems.

If the green light flashes, the fiber optic card is powered on. If it does not light up, check for poor contact at the power PIN.

If the green light is ON, the fiber optic cards are communicating normally.

If it is OFF, the communication between the cards has not been established. Check whether the fiber cables are damaged.

If there is an error in the optical fiber communication, the red light will be ON.

Table 1-8

Reactor
During the parallel control, if there is no reactor installed on the output side, some of the current from the drive flows into the parallel drive and causes circulating current. Install an output reactor can prevent the above circulating current occurs. Refer to the user manual of each drive models in Delta Download Center for reactor selections.

Parallel circulating current reactor
Parallel circulating current reactor - Example 1 - Part 1
Parallel circulating current reactor - Example 1 - Part 2

Figure 1-2

Parallel Circulating Current Reactor Delta # kW Rated
Current
(A)
Inductance
Value
(μH)
Saturated
Current
(Arms)
Consumption
(W)
Dimension
(mm)
UL
Certification
DR505LP004P 220 505 4.35 757.5 96.2 As shown in the figure above Pass
250

Table 1-9

Parallel circulating current reactor - Example 2
Figure 1-3

Parallel Circulating Current Reactor Delta # kW Rated Current
(A)
Inductance
Value
(μH)
Saturated
Current
(Arms)
Consumption
(W)
Dimension
(mm)
UL
Certification
DR616LP004P 280 616 3.77 924 124 As shown in the figure above Pass
315

Table 1-10

Parallel circulating current reactor - Example 3
Figure 1-4

Parallel Circulating Current Reactor Delta # kW Rated
Current
(A)
Inductance
Value
(μH)
Saturated
Current
(Arms)
Consumption
(W)
Dimension
(mm)
UL
Certification
DR770LP003P 355 770 2.93 1155 126.7 As shown in the figure above Pass
400

Table 1-11

Parallel circulating current reactor - Example 4
Figure 1-5

Parallel Circulating Current Reactor Delta # kW Rated
Current
(A)
Inductance
Value
(μH)
Saturated
Current
(Arms)
Consumption
(W)
Dimension
(mm)
UL
Certification
DR930LP002P 450 930 2.41 1395 174 As shown in the figure above Pass
500

Table 1-12

Parallel circulating current reactor - Example 5
Figure 1-6

Parallel Circulating Current Reactor Delta # kW Rated
Current
(A)
Inductance
Value
(μH)
Saturated
Current
(Arms)
Consumption
(W)
Dimension
(mm)
UL
Certification
DR1212LP002P 560 1212 1.82 1818 209.5 As shown in the figure above Pass
630

Table 1-13

Wiring

After removing the front cover, verify that the power and control terminals are clearly noted. Read the following precautions before wiring.

  • Turn off the AC motor drive power before doing any wiring. A charge with hazardous voltages may remain in the DC bus capacitors even after the power has been turned off for a short time. Measure the remaining voltage with a DC voltmeter on +1/DC+ and DC- before doing any wiring. For your safety, do not start wiring before the voltage drops to a safe level (less than 25 VDC). Installing wiring with a residual voltage may cause personal injury, sparks, and short circuit.
  • Only qualified personnel familiar with AC motor drives are allowed to perform installation, wiring and commissioning. Make sure the power is turned off before wiring to prevent electric shock.
  • Make sure that power is only applied to the R/L1, S/L2 and T/L3 terminals. Failure to comply may result in damage to the equipment. The voltage and current must be in the range indicated on the nameplate. Refer to the nameplate information in the User Manual of each models for details:
  • All units must be grounded directly to a common ground terminal to prevent damage from a lightning strike or electric shock and reduce noise interference.
  • Tighten the screws of the main circuit terminals to prevent sparks caused by screws loosened due to vibration.
  • For your safety, choose wires that comply with local regulations when wiring.
  • Check the following items after finishing the wiring:
  1. Are all connections correct?
  2. Are there any loose wires?
  3. Are there any short circuits between the terminals or to ground?

Wiring diagram

Power input terminal Supply power according to the rated power specifications indicated in the manual.
NFB or fuse There may be a large inrush current during power on.
Electromagnetic contactor

Switching the power ON/OFF on the primary side of the electromagnetic contactor can turn the drive ON/OFF, but frequent switching can cause machine failure. Do not switch ON/OFF more than once an hour.

Do not use the electromagnetic contactor as the power switch for the drive; doing so shortens the life of the drive.

Brake module
&
Brake resistor (BR)
Used to shorten the deceleration time of the motor.
AC reactor
(input terminal)

When the mains power supply capacity is greater than 500 kVA, or when it switches into the phase capacitor, the instantaneous peak voltage and current generated may destroy the internal circuit of the drive.

It is recommended that you install an input side AC reactor in the drive. This also improves the power factor and reduces power harmonics.

When the PN is connected, an input reactor must be installed to ensure proper rectifier operation.

The wiring distance should be within 10 m.

Zero phase reactor

Used to reduce radiated interference, especially in environments with audio devices, and reduce input and output side interference.

The effective range is AM band to 10 MHz.

EMC filter Can be used to reduce electromagnetic interference.
Fiber communication card Transmit information between master and slave through the fiber communication card.
Output Reactor To prevent circulating currents from damaging the variable frequency startup during parallel connection, ensure the voltage phase sequence on both sides is the same. While the reactor has no directionality for input and output, maintaining this phase sequence is crucial.

Table 2-1

Parallel Application Introductions

Parameter Overview

The following describes the parameters related to parallel connection:

You can set this parameter during operation

00-62 Six-Phase Motor Master and Slave Settings
Settings 0–2
0: Single unit mode
1: Master mode
2: Slave mode
Default: 0
00-63 Optical Fiber Communication Card Software Version
Settings Read only Default: Read only
Displays the current software version of the optical fiber communication card.
00-65 Six-Phase Motor Coil Offset Angle
Settings -360.0–360.0 Default: 0
Depending on the design considerations of the six-phase motor winding, the two windings may need to be electrically offset. Common offset angles are 0 degrees, 30 degrees, and 60 degrees. In the control architecture, the main control output voltage is typically adjusted by 30 degrees based on the motor structure before output. However, due to possible process or structural errors, the offset angle parameter can be fine-tuned to ensure consistency between the master and slave controls.

Parallel Setup Steps

C2000 Series Settings
The following is the setting process and descriptions of C2000 series parallel connection, re-power the drive after completing the set up.

C2000 Series Tuning

  • Control and communication parameters can be set on the master drive
  • Motor and protection parameters must be identical on both the master and slave drives
  • Currently, only speed mode (Pr.00-10=0) is supported

Master Drive Parameter Setting

  1. Set Pr.00-02 = 10 (Parameter reset).
  2. Set motor parameters in the Parameter Group 05.
  3. Set Pr.00-62 = 1 (Master unit).
  4. Check Pr.00-63 (Fiber communication card firmware version).
  5. Set Pr.00-64 = 8 (Keypad setting: bit3 = 1, Parallel start).
  6. Set Pr.00-11 according to the required mode (Currently supports IMVF and PM Sensorless).
  7. Set Pr.00-17 carrier frequency (less than 6 kHz).
  8. Set Pr.11-00 = 9.
  9. Set Pr.10-53 = 1 (Only required for PM Sensorless).
  10. Set parameters for Group 10 and Group 11.
  11. Set Pr.00-04 to obtain the motor information: Pr.00-04=73 (output current), 74 (output power) and 75 (output torque).

Slave Side Parameter Setting:

  1. Set Pr.00-02 = 10 (Reset parameters).
  2. Set motor parameters in Parameter Group 05.
  3. Set Pr.00-62 = 2 (Slave unit).
  4. Check Pr.00-63 (Fiber communication card firmware version).
  5. Set Pr.00-64 = 8 (bit3 = 1, Parallel start).
  6. Set Pr.01-34 = 2 (minimum frequency)
  7. Set Pr.00-11 according to the required mode (Currently supports IMVF and PM Sensorless).
  8. Set Pr.00-17 to match the master drive's setting value.
  9. Set Pr.00-20 = 9.
  10. Set Pr.00-21 = 6.
  11. Set Pr.11-00 = 9.
  12. Set Pr.10-53 = 0.
  13. Set parameters for Group 10 and Group 11.

Motor Parameter Autotuning

  • In parallel model, the master drive must switch back to single unit mode before executing motor parameter autotuning, Pr.00-62 = 1 (master mode) changes to 0 (single unit mode). Be aware that the output side wiring of the Slave must be removed (as shown in the following figure), otherwise there is a risk of the Slave boosting the voltage.
    Motor Parameter Autotuning
  • When driving a permanent magnet synchronous motor, execute the parameter autotuning according to Pr.05-00 settings.
  • When driving an inductance motor and using speed tracking function by the motor vector flux (Pr.07-12 = 4), set the simple rolling auto-tuning for IM according to Pr.05-00 settings.
  • After the autotuning is completed, re-connect the output wiring to the Slave and change the single unit mode back to master mode (Pr.00-62 = 1).

Fault Codes and Descriptions

Summary of Fault Codes

ID No. Fault Name
213 Slave Error (SLEr)
214 SPI Tx Error (CdE1)
215 Fiber Card UART Error (PUtE)
216 SPI Rx Error (CdE2)
217 PCOM Data Loss (PDlE)
218 PCOM Torque Error (PSTq)

  1. Display error signal
  2. Abbreviate error code
  3. Display error description
ID Display on LCD Keypad Fault Name Fault Descriptions
213 Slave Error
(SLEr)
Slave error: this fault code only displays on the Master drive.
Action and Reset
Action Condition Slave Error
Action Time Act immediately
Fault Treatment Parameter N/A
Reset Method Manual reset
Reset Condition Clear slave error codes before manual reset
Record Yes
Cause Corrective Actions
Slave Error Check slave error code and resolve the issue to reset.
ID Display on LCD Keypad Fault Name Fault Descriptions
214 SPI Tx Error
(CdE1)
CRC error occurs during data transmission from the drive to the fiber card
Action and Reset
Action Condition CRC error occurs during data transmission from the drive to the fiber card
Action Time Act immediately
Fault Treatment Parameter N/A
Reset Method Manual reset
Reset Condition The drive and fiber card reconnect normally
Record Yes
Cause Corrective Actions
Fiber card abnormal
  1. Check if the fiber card is installed firmly.
  2. If the issue persists, replace the fiber card, and contact Delta.
ID Display on LCD Keypad Fault Name Fault Descriptions
215 Fiber Card UART Error
(PUtE)
UART communication error between fiber cards
Action and Reset
Action Condition UART communication error between fiber cards
Action Time Act immediately
Fault Treatment Parameter N/A
Reset Method Manual reset
Reset Condition Communication between master and slave fiber cards has been restored
Record Yes
Cause Corrective Actions
Abnormality between fiber cards or cables
  1. Check if the fiber cards or fiber cables is installed firmly
  2. If the issue persists, replace the fiber cards and cables, and contact Delta.
ID Display on LCD Keypad Fault Name Fault Descriptions
216 SPI Rx Error
(CdE2)
CRC error occurs during data transmission from the fiber card to the drive
Action and Reset
Action Condition CRC error occurs during data transmission from the fiber card to the drive
Action Time Act immediately
Fault Treatment Parameter N/A
Reset Method Manual reset
Reset Condition The drive and fiber card reconnect normally
Record Yes
Cause Corrective Actions
Abnormality between fiber cards or cables
  1. Check if the fiber cards or fiber cables is installed firmly
  2. If the issue persists, replace the fiber cards and cables, and contact Delta.
ID Display on LCD Keypad Fault Name Fault Descriptions
217 PCOM Data Loss
(PDIE)
UART disconnect between fiber cards
Action and Reset
Action Condition UART disconnect between fiber cards
Action Time Act immediately
Fault Treatment Parameter N/A
Reset Method Manual reset
Reset Condition Reconnect between fiber cards
Record Yes
Cause Corrective Actions
Fiber card or fiber cable disconnection Turn off the AC motor drive power and check if the fiber cards and cables are securely connected
ID Display on LCD Keypad Fault Name Fault Descriptions
218 PCOM Torque Error
(PSTq)
Abnormal torque distribution
Action and Reset
Action Condition More than 50% difference in torque distribution between master and slave
Action Time Act immediately
Fault Treatment Parameter N/A
Reset Method Manual reset
Reset Condition Reset immediately
Record Yes
Cause Corrective Actions
More than 50% difference in torque between master and slave
  1. Check if the drive parameters meet the description in parallel control manual.
  2. Check if the drive wiring is correctly installed on the motor side.

SAFETY INSTRUCTIONS

PLEASE READ PRIOR TO INSTALLATION FOR SAFETY.

  • Disconnect AC input power before connecting any wiring to the AC motor drive.
  • When wiring, turn off the AC motor drive power first. It takes a certain time for the internal DC capacitor to discharge. A charge may still remain in the DC link capacitors with hazardous voltages before the POWER LED is OFF. Do NOT touch the internal circuits and components. To avoid damage, use a voltmeter for testing. Wiring only after the voltage is lower than the safety voltage value of 25 VDC. If the AC motor drive does not fully discharge, there will be residual voltage inside. Any wiring at this time causes short-circuit and fire. It is strongly suggested to operate the wiring under novoltage conditions to ensure personnel safety.
  • There are highly sensitive MOS components on the printed circuit boards. These components are especially sensitive to static electricity. Take anti-static measure before touching these components or the circuit boards.
  • Never modify the internal components or wiring.
  • Ground the AC motor drive by using the ground terminal. The grounding method must comply with the laws of the country where the AC motor drive is to be installed.
  • Do NOT install the AC motor drive in a location with high temperature, direct sunlight or inflammable materials or gases.

  • Never connect the AC motor drive output terminals U/T1, V/T2 and W/T3 directly to the AC mains circuit power supply.
  • After finishing the wiring of the AC motor drive, check if R/L1, S/L2, and T/L3 are short-circuited to ground with a multimeter. Do NOT power the drive if short circuits occur. Eliminate the short circuits before the drive is powered.
  • The rated voltage of power system to install motor drives is listed below. Ensure that the installation voltage is in the correct range when installing a motor drive.
  1. For 230V models, the range is between 170–264V.
  2. For 460V models, the range is between 323–528V.
  3. For 575V models, the range is between 446–660V.
  4. For 690V models, the range is between 446–759V.
  • Refer to the table below for short circuit rating:
Model (Power) Short circuit rating
230V / 460V 100 kA
575V (2–20HP) 5 kA
690V (25–50HP) 5 kA
690V (60–175HP) 10 kA
690V (215–335HP) 18 kA
690V (425–600HP) 30 kA
690V (745–850HP) 42 kA
  • Only qualified persons are allowed to install, wire, and maintain the AC motor drives.
  • Even if the three-phase AC motor is stopped, a charge with hazardous voltages may still remain in the main circuit terminals of the AC motor drive.
  • The performance of electrolytic capacitor will degrade if it is not charged for a long time. It is recommended to charge the drive which is stored in no charge condition every 2 years for 3–4 hours to restore the performance of electrolytic capacitor in the motor drive. Note: When power up the motor drive, use adjustable AC power source (ex. AC autotransformer) to charge the drive at 70–80% of rated voltage for 30 minutes (do not run the motor drive). Then charge the drive at 100% of rated voltage for an hour (do not run the motor drive). By doing these, restore the performance of electrolytic capacitor before starting to run the motor drive. Do NOT run the motor drive at 100% rated voltage right away.
  • Pay attention to the following precautions when transporting and installing this package (including wooden crate and wood stave)
  1. If you need to deworm the wooden crate, do NOT use fumigation or you will damage the drive. Any damage to the drive caused by using fumigation voids the warranty.
  2. Use other methods, such as heat treatment or any other non-fumigation treatment, to deworm the wood packaging material.
  3. If you use heat treatment to deworm, leave the packaging materials in an environment of over 56°C for a minimum of thirty minutes.
  • Connect the drive to a three-phase three-wire or three-phase four-wire Wye system to comply with UL standards.
  • If the motor drive generates leakage current over AC 3.5 mA or over DC 10 mA on a grounding conductor, compliance with local grounding regulations or IEC61800-5-1 standard is the minimum requirement for grounding.

Documents / Resources

References

Download manual

Here you can download full pdf version of manual, it may contain additional safety instructions, warranty information, FCC rules, etc.

Download Delta C2000 Plus, C2000-HS, C2000-R Manual

Advertisement

Need help?

Need help?

Do you have a question about the C2000 Plus and is the answer not in the manual?

Questions and answers

Table of Contents
