Intelligent Flight Battery - RUKO F11GIM User's Manual - Safety Manual

3.6 Intelligent Flight Battery

The F11GIM intelligent flight battery has a capacity of 2500mAh, a
rated voltage of 11.1 V, and with charge and discharge management
functions. This battery uses high-energy and large-capacity batteries
to increase the flight time of the Aircraft.
Battery Features
Balance Protection: Automatically balance the internal battery cell
voltage to protect the battery.
Overcharge Protection: Overcharge will seriously damage the
battery. When the battery is full, remove the charger device in time.
Over-discharge Protection: Over-discharge will seriously damage
the battery. When the battery is not used for flight, the battery will
automatically discharge to protect the battery life.
Short Circuit Protection: When the battery detects a short circuit,
the output will be cut off to protect the battery.
Easy Charging: No need for a dedicated power adapter, just Type-C
charger and USB charging head.
Please read carefully and strictly abide by Ruko's Requirements
in this Manual, Disclaimer and Safety Summary, and stickers on the
battery surface before using the battery. The user shall bear the
consequences caused by failure to use it as required.
Using the Battery
Install the Intelligent Flight Battery into the battery compartment and
push it down until you hear a "click" from the battery buckle, indicating
that it pops up and locks. Make sure the battery is in place.
To remove the battery, press the buckles on both sides of the battery
and pull it out of the battery compartment.
