GPS Status
③
Used to display the GPS signal strength, 3 bars indicate that the GPS
signal meets the flight requirements, 1 or 2 bars indicate that the GPS
signal is weak, and the flight position needs to be changed.
Intelligent Flight Battery Information Bar
④
Display the current intelligent flight battery power and voltage, and
the power progress bar displays.
System Settings
⑤
System settings include flight range settings, data recording, English
and metric unit switching, route display, reminder information and
voice prompt settings.
SD Card
⑥
Check the SD card capacity and formatting.
Shooting Mode
⑦
Choose to take a picture or record a video.
Shutter / Record Button
⑧
Tap to start shooting photos or recording video.
Playback
⑨
Tap to enter playback and preview photos and videos as soon as they
are captured.
Recording
⑩
Tap this button to trigger the mobile phone end of the app to
start/stop recording the voice.
Flight Status Parameters
1 1
D N/A: Flying distance
H N/A: Flying height
DS N/A: Flying speed
VS N/A: Ascent/decrease speed
Attitude Indicator
1 2
Display information of the orientation of the Aircraft, and position of
the Transmitter .
Remote controller
position
Aircraft
orientation
