F 11 GIM User Manual

3.5 Propellers

The propellers on the adjacent motors of the F11GIM are forward and
reverse propellers. The two propellers on the same motor are the
same, and the propellers are marked with A and B respectively. The
rotation directions of the propellers with the same mark are different.
Propellers
A
B
Installation location
Attaching the Propellers
Taking the camera direction as the front, the left front arm and right
rear arm must be equipped with propellers marked with A; the right
front arm and left rear arm must be equipped with propellers marked
with B. Use a screwdriver to install and make sure the screws are
tightened.
Detaching the Propellers
Use the screwdriver to detach the propellers from the motors.
Please use the propellers provided by Ruko, and do not mix
propellers of different types.
Please check whether the propeller is installed correctly and tightly
before each flight.
Before each flight, please check to make sure that the propellers are
in good condition.
Make sure that the ESC emits a tone after the Aircraft is powered on.
25
Copyright ©2022 Ruko All Rights Reserved.
B
A
Installed to the motor with A
mark on the arm
Mark A
A
A
Mark B
B
B
Installed to the motor with B
mark on the arm
