When the Android phone is connected to Aircraft WiFi (named RUKO-GIM-
******), as the Aircraft WiFi has no network, wait for about 10-40 seconds
on the phone WiFi setting page, the phone will pop up the network setting
option to ask whether to continue to connect to Aircraft WiFi, please set it
continue to use Aircraft WiFi, so as not to cause the APP to be unable to
see the image transmission screen.
Please turn off the VPN switch of the phone to avoid the app not being
able to see the image transmission screen.
If the mobile phone is set to priority on Internet speed and the app cannot
see the image transmission screen, please set the mobile phone to
airplane mode and try.
Aircraft image transmission WiFi is 5.8G, mobile phone WLAN function
must be supported; dual-band WiFi, 2.4G+5.8G, can be applied.
Calibrate the compass
At this time, you need to follow the prompts to pick up the Aircraft
①
at a distance of 3.28 ft from the ground and rotate the Aircraft
horizontally for 1-2 laps until the app interface prompts to enter the
vertical calibration.
GeomagneticHor Calibration
3.28ft
Plaese place the aircraft 1 meter high
1
on the groud and rotate it
horizontally for 2-3times .
Pick up the Aircraft at a distance of 3.28 ft from the ground, and
②
rotate the Aircraft 1-2 laps vertically with the camera facing upwards
until the prompt of vertical calibration on the app interface disappears.
After the compass calibration is completed, place the Aircraft on a
level ground. At this time, the front arm of the Aircraft has a white
light and the rear arm has a blue light, and the app prompts that the
compass calibration is complete.
GeomagneticHor Calibration
3.28ft
Please place the airctaft 1 meter high on
the ground, nose up, and rorate it 2-3
times.
F1 1 GIM User Manual
Geocalibration finished!
