14+
for age
Quick Guide &
Safety Disclaimer
v2.0
CONTACT US FOR MORE TECH SUPPORT
+ 1 949-394-4635
Mon-Sun 6PM-4AM(PST)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F11GIM2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RUKO F11GIM2

Summary of Contents for RUKO F11GIM2

  • Page 1 for age Quick Guide & Safety Disclaimer v2.0 CONTACT US FOR MORE TECH SUPPORT + 1 949-394-4635 Mon-Sun 6PM-4AM(PST)

  • Page 2: Download App

    Download App RUKO DRONE Download on the App Store RUKO DRONE Download for Android RUKO DRONE App Charge the Batteries Self-equipped Copyright ©2022 Ruko All Rights Reserved.
  • Page 3 Lift and then pull Copyright ©2022 Ruko All Rights Reserved.
  • Page 4 Unfold the antenna Unfold the handle Copyright ©2022 Ruko All Rights Reserved.
  • Page 5 Select an Open Flight Area Height≥65ft Copyright ©2022 Ruko All Rights Reserved.
  • Page 6 Press and hold the button until the aircraft plays startup sound. GPS Mode Press once and then press again to turn on the transmitter. Note: The drone and transmitter linking takes around 40 seconds. Copyright ©2022 Ruko All Rights Reserved.

  • Page 7: Calibrate The Compass

    Please refer to user manual for more details. F11 GIM2 RUKO - GIM 2 -****** Tap "CONTROLS" icon Calibrate the Compass Rotate the aircraft horizontally 360°. ( About 1-2 turns ) Rotate the aircraft vertically 360°. ( About 1-2 turns ) Copyright ©2022 Ruko All Rights Reserved.
  • Page 8 Calibrate the Gyroscope Push joysticks to 11 & 1 o'clock position. ( About 2 seconds ) A level ground Gimbal Self-inspection Put on a level surface. ( About 20 seconds ) Copyright ©2022 Ruko All Rights Reserved.
  • Page 9 Tips: 1. The searching time depends on the flight environment. 2. If unsuccessful, the motors can't be started. Start the Motors Push joysticks to 5 & 7 o'clock position. ( About 2 seconds ) Take off Push up the left stick. Copyright ©2022 Ruko All Rights Reserved.
  • Page 10 Check the Flight Guide in the App Search “Ruko F11 GIM 2 Scan QR Code for More Quick Start” on YouTube for Tech and Video Support First Flight CONTACT US FOR MORE TECH SUPPORT Printed in China. Copyright ©2022 Ruko All Rights Reserved.

  • Page 11: Common Problems And Solutions

    GPS signal is Please fly the Aircraft in an unstable. Flying near open area free of obstacles buildings and in within the circle of radius obstructed places 32.81 ft(10 meters) Copyright ©2022 Ruko All Rights Reserved.
  • Page 12 After complete the compass The compass is in calibration, place the drone calibrating on a level ground Copyright ©2022 Ruko All Rights Reserved.
  • Page 13 Please do keep the drone's Didn't keep the WiFi connectted when the drone's network when phone pop up reminder that trying to connect the "This network has no internet drone's WiFi access" Copyright ©2022 Ruko All Rights Reserved.
  • Page 14 Cannot charge unstable voltage amperage output(2-3A) battery/Cannot fully output charge battery Please use the original Using inferior factory charging cable to charging cables charge Copyright ©2022 Ruko All Rights Reserved.
  • Page 15 The product has slight We tested all Aircraft before shipping. Therefore, it marks before shipping is inevitable that there will be slight traces. However, it can be guaranteed that all Aircraft are 100% brand new Copyright ©2022 Ruko All Rights Reserved.

  • Page 16: Safety At A Glance

    Safety at a Glance The Ruko F11 GIM2 is NOT a toy and is NOT suitable for people under the age of 14. 1. Glossary The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product:...

  • Page 17: Flight Environment Requirements

    Any personal injury property damage, legal disputes and all other adverse events caused by the violation of the safety instructions or due to any other factor, WILL NOT be Ruko's responsibility. 3. Flight Environment Requirements It is suggested to fly in areas below 9000 feet above sea level, choose an open field of 32 feet in diameter outdoor, far away from...
  • Page 18 Keep the aircraft at least 9.8 feet above the water surface when flying over water. It is forbidden to fly indoors. Only fly in authorized areas. To learn more about aircraft requirements,please visit the Federal Aviation Administra- tion's aircraft page https://www.caa.co.uk/home/ Copyright ©2022 Ruko All Rights Reserved.
  • Page 19 If the aircraft has not been used for a month, the battery must be removed to prevent the battery from being in a long-term low-power discharge state. Use 5V/3A charging plugs. Fast charging USB Adapter (5V/3.0A ) plugs exceeding 5V/3A are prohibited. （Not included） Copyright ©2022 Ruko All Rights Reserved.
  • Page 20 flight as the temperature may be too high. Wait until it cools down to room tempera- Overheating warning ture before charging again. Due to the battery current output, slight hotness is normal while flying. Copyright ©2022 Ruko All Rights Reserved.

  • Page 21: Pre-Flight Checklist

    6. Problems You May Encounter Flight preparation Back The aircraft direction ① Stay away from People Please pay attention to the direction of the aircraftwhen flying. The camera direction is the forward of the aircraft. Front Unfold arms Copyright ©2022 Ruko All Rights Reserved.
  • Page 22 Reserve enough power for the drone to return home. When doing ④ long distance flight test, please make sure to reserve enough power for the drone to return, escpecially in the windy weather, as the battery will be comsumed more quickly. Copyright ©2022 Ruko All Rights Reserved.
  • Page 23 Do not turn on the aircraft when it is on desk or hollow wooden ③ floor. They will amplify the small vibrations into high-frequency vibrations, which will cause the gimbal cannot work. On the desk On the hollow wooden floor Copyright ©2022 Ruko All Rights Reserved.
  • Page 24 Put the aircraft on a level surface after calibration, then the gimbal will start to work after 20 seconds. Before Start During Compass and Gyro calibration Put on a level surface and wait for 20 seconds Copyright ©2022 Ruko All Rights Reserved.
  • Page 25 WiFi. Make sure allow all the permissions ③ required when connecting with app. If failed at connection, please go to the phone "set- ting" to allow all the permissions. Copyright ©2022 Ruko All Rights Reserved.
  • Page 26 The RTH can't be cancelled, but you can adjust the landing position by moving the joysticks. return altitude 16 ft current altitude 16 ft 98 ft RTH within 98 ft Copyright ©2022 Ruko All Rights Reserved.
  • Page 27 fly against the wind will consume more power. setted return altitude 65 ft current altitude 16 ft >98 ft RTH further than 98 ft CONTACT US FOR MORE TECH SUPPORT Printed in China. Copyright ©2022 Ruko All Rights Reserved.
  • Page 28 CONTACT US FOR MORE TECH SUPPORT + 1 949-394-4635 Mon-Sun 6PM-4AM(PST) rukodrone@gmail.com +86 19129317359...
