LINET LINIS SafetyPort Instructions For Use Manual page 7

Datapoints (monitored
statuses)
Lowest position +
Heightlock
Backrest Angle + Lock
Trendelenburg
Lateral tilt
Patient weight
Calfrest Angle + lock
Foot Control Lock
Integrated Mattres
Bed Type
Disconnected
D9U001SW2-0110_03
Visual Signalization
20°
ATX 15°
L 10°
120 lbs/Kg
20*
Opticare -X/Opticare /
Symbioso / -
MC, MCLE, MCX,
E5, E4, E3, E3XC
Disconnected
Meaning
Lowest position is ON.
Lowest position is OFF.
Lowest position is ON, Heightlock is activat-
ed.
Lowest position is OFF, Heightlock is activat-
ed.
Shows the current angle of Backrest in de-
grees and if locked, then it shows a lock next
to the angle
Shows the current longitudinal tilt - values: TX
angle value (e.g. TX 10 meaning 10 degrees
angle, feet higher than head) / ATX angle val-
ue (e.g. ATX 15 meaning 15 degrees angle,
head higher than feet )
Shows the current lateral tilt - values: R angle
value (e.g. R 15, patient tilted 15 degrees
to the right) / L angle value (e.g. L10 patient
tilted 10 degrees to the left)
Current weight of the patient.
Shows the current angle of calfrest in de-
grees and if locked, then it shows a lock next
to the angle.
Icons of open and closed lock based on
whether the Foot Control is locked or not.
Indicates if any active mattress is connected
to the bed.
Value is inserted by the technician during the
installation process.
If the bed is disconnected/ not sending data,
there will be no data shown in the table and
whole row will be covered by "disconnected"
overlay. Only the last location, name and note
are persisted.
7/52
