Parameter HL7 OBX ID
Error or
Stop Code 0041^LINIS
D9U001SW2-0110_03
Value
Controllers
0 Inactive
1 Going to the initial position
2 Ongoing Settings of angles and time in diff erent positions
3 Going from the neutral position to fi rst left position
4 Standing still the fi rst left position (when going to the left)
5 Going from the fi rst left position to second left position
6 Standing still in the second left position
7 Going from the second left position back to fi rst left position
8 Standing still in the fi rst left position (when going to the right)
9 Going from the fi rst left position back to the neutral position
10 Standing still in the neutral position in the middle of the cycle
11 Going from the neutral position to the fi rst right position
12 Standing still in the fi rst right position (when going to the right)
13 Going from the fi rst right position to the second right position
14 Standing still in the second right position
15 Going from the second right position back to the fi rst right position
16 Standing still in the fi rst right position (when going back to neutral)
17 Going from the fi rst right right position back to the neutral position
18 Standing still in the neutral position in the end of the cycle
PB43
1
Foot control pressed after
2
STOP.
3
Two buttons pushed simulta-
4
neously longer than 1 second.
Keyboard not released after
5
system start.
Main control box temperature
6
exceeded.
7 Column current overload 0.
8 Column current overload 1.
9
Actuator current overload –
10
backrest.
Actuator current overload –
11
thighrest.
Stopped due to resistance on
12
the same function.
Short circuiton on analog
13
control (RC detection).
101 GO button not active.
102 Locked function.
103
104
105
106
Function blocked during one
111
fault state.
112
113
114
115
116
121
122
123 Absolute scale overload.
124
125
126 Safestop
Description
PB46
Unexpected lateral tilt
detected by main control box
motherboard accelerometer.
Foot control pressed after
STOP.
Display button pressed after stop.
Two buttons pushed simulta-
neously longer than 1 second.
Keyboard not released after
system start.
Main control box temperature
exceeded.
Column current overload 0.
Column current overload 1.
Column current overload 2.
Actuator current overload –
backrest.
Actuator current overload –
thighrest.
Stopped due to resistance on
the same function.
Short circuiton on analog con-
trol (RC detection).
GO button not active.
Locked function.
X-ray cassette inserted
incorrectly.
Siderails folded down during
lateral tilt.
Backrest angle greater than
30° during lateral tilt.
Lateral tilt stopped at 15°
when using foot control.
Function blocked during one
fault state.
Function blocked during
active ALT.
Stopped due to risk of colli-
sion when bed is tilted.
Stopped in zero position.
Collision when exceeding thresh-
old limit of calfrest and footrest.
Scale overload – tilt only to 15°.
Column potentiometer defect.
Stopped at 15° during lateral
movement patient transfer.
Absolute scale overload.
Starting or running ALT on battery.
Use manual mattress CPR
(not stopping, only pop up).
E3/
MC E5 E4
E3XC
1 1 1 1
