CUSA EXcel
Console Full Function Testing
Console Testing to IT0032 Issue 2
5.2 Bias 24v Duel DC power supply
24Volt Duel DC power supply
output (2)
Measure at J8
Set to 24Volts
Tolerances 23.5v to 24.5v
'C' Type Ultrasonic PCB
There are no adjustments to be
made on these power supplies
