Holding register Name
(Protocol)
40139 - 40140 Error state
(138-139)
40141 Acknowledge
(140)
40142 Alarm history index
(141)
40143 Alarm history error
(142) code
40198 State float swiches
(197)
40204 Set points water
(203) level 1
40205 Set points water
(204) level 2
40206 Set points water
(205) level 3
40212 Set points water
(211) level 1
40213 Set points water
(212) level 2
40214 Set points water
(213) level 3
40220 Dry run level
(219)
40222 High water level
(221)
Installation and operating instructions • Wilo-Control EC-L • Ed.04/2022-09
Data type Scale & unit
BITMAP32
BOOL
UINT16
UINT16 0.1
BITMAP
UNIT16 1 cm
UNIT16 1 cm
UNIT16 1 cm
UNIT16 1 cm
UNIT16 1 cm
UNIT16 1 cm
UNIT16 1 cm
UNIT16 1 cm
Key
* R = read-only, RW = read- and write-accessible
Elements Access*
0: Sensor error R
1: P max
2: P min
3: FC
4: TLS
5: Pump 1 Alarm
6: Pump 2 Alarm
7: Pump 3 Alarm
8: Pump 4 Alarm
9: Pump 5 Alarm
10: Pump 6
Alarm
11: -
12: -
13: Frost
14: Battery Low
15: High water
16: Priority off
17: Redundancy
18: Plausibility
19: Slave com-
munication
20: Net supply
21: Leakage
W
RW
R
0: DR R
1: Ps off
2: P1 on
3: P2 on
4: HW
RW
RW
RW
RW
RW
RW
RW
RW
en
Added
31,000
31,000
31,000
31,000
31.102
31.102
31.102
31.102
31.102
31.102
31.102
31.102
31.102
