Fig. 50: Menu 5.65
Fig. 51: Menu 5.66
Fig. 52: Menu 5.67
Fig. 53: Menu 5.68
38
Menu no. 5.65
Software version: All
Description Automatic resetting of error "Dry run"
Value range on, off
Factory setting on
Explanation If the fill level is over the dry run level again, the error message
"dry run" is automatically reset.
•
•
Menu no. 5.66
Software version: All
Description Integrated buzzer On/Off
Value range off, error
Factory setting off
Explanation Switching the buzzer on or off:
•
•
NOTICE! Alarm in the event of interrupted power supply: To
switch off the internal buzzer if there is a built-in re-
chargeable battery, remove the battery!
Menu no. 5.67
Software version: All
Description Output (24 V=, max. 4 VA) On/Off for an external signalling unit
Value range off, error
Factory setting off
Explanation Separate output to switch an external alarm signal on or off:
•
•
Menu no. 5.68
Software version: All
Description Mains connection rotating field monitoring On/Off
Value range on, off
Factory setting on
Explanation Integrated rotating field monitoring for the mains connection.
If no clockwise rotating field is present, an error message oc-
curs.
•
•
NOTICE! When operating the switchgear via a single-phase
current connection, switch off this function!
Installation and operating instructions • Wilo-Control EC-L • Ed.04/2022-09
on = function activated
off = function deactivated
off = buzzer off
error = buzzer on
off = output deactivated
error = output activated
off = rotating field monitoring deactivated
on = rotating field monitoring activated
