6 ETS Installation and Operation Manual
Figure 3: ETV Platinum Plus Controls, Indicators, and Connections
Item
1 Output Status LEDs
See "ETV Platinum Plus Control Module Output
Status LEDs" on page 22.
2 Digital Display
See "Display and Variable‐Function Buttons" on
page 22.
3 Variable‐Function Buttons
See "Display and Variable‐Function Buttons" on
page 22.
4 Internet/BACnet/Modbus Connection
Communications interface
059326‐00 Rev D
1
8
Description
7 6
Item
5 Prove Input Connection
6 EMS Remote Setpoint Connection
7 Program/Run Switch
Places the ETV Platinum Plus in programming
mode or run (normal operation) mode.
NOTE: Programming mode may be password
protected.
8 Communication Modem Reset
NOTE: Used if internet communication is lost for
more than one hour.
2
3
5 4
Description
