heat-timer ETS Installation And Operation Manual page 19

6. Connect the GROUND line to the GREEN wire pigtail using the provided wire nut. DO NOT use the neutral
line as the earth ground!
ELECTRICAL SHOCK HAZARD! To avoid the risk of electric shock, DO NOT re‐connect electrical
power until ALL wiring to the ETS assembly is completed. Failure to do so may result in severe
personal injury or death.
7. After all wiring to the ETS assembly is complete, replace the Disconnect Panel front plate and secure it in
place with four screws.
8. Complete any communication or optional field wiring as outlined in ETV Platinum Plus Wiring on page
41 before proceeding to Step 9.
9. Apply power to the ETS assembly.
NOTE: Once power is supplied to the ETS it will take approximately 2 minutes to fully charge the
Lost of Power (LOP) capacitor in the ETV valve actuator(s). Once fully charge the LOP capacitor will
be able to power the actuator and position the valve to a full COLD position during a loss of power
condition.
Heat‐Timer Corp.
WARNING
Installation Instructions 19
059326‐00 Rev D
