Installation and Operation Manual
Hydronic/Hot Water Outdoor Reset
Multiple Boiler Heating Controls
C O R P O R A T I O N
SELECT
ADJUST
BACK
BOILER
DAY
PREV /NEXT
ENCLOSED
ENERGY
MANAGEMENT
EQUIPMENT
LISTED
OUTPUT RATINGS:
120VAC, 6A RESISTIVE
1A PILOT DUTY
15A TOTAL
FOR ALL CIRCUITS
INPUT RATINGS:
115VAC 60Hz
30VA MAX
USE COPPER WIRE,
CLASS 1 WIRE ONLY
SAFETY
GROUND
MUST BE
CONNECTED
MADE IN U S A
This Heat-Timer control is strictly an operating control; it should
never be used as a primary limit or safety control. All equipment
must have its own certified limit and safety controls required by local
codes. The installer must verify proper operation and correct any
safety problems prior to the installation of this Heat-Timer control.
R
MENU FUNCTIONS
enters menus or accepts changes
selects menu items or changes settings
SYS= 125
returns to previous menu
TGT= 126
selects boiler menus or next boiler
<AB>
selects next day
HIGH
steps through output status
AUTO
HELP
BYPASS
99RA
PUMP
A
2
3
4
5
5A
6
7
PUMP
A
WARNING
HWRQ
Platinum
DO NOT APPLY ANY VOLTAGE
o
o
F
OD= 31
F
o
F
DAY
CD
EF
LOW
OFF
PREV
NEXT
BOILER
(DEL)
(DAY)
B
C
D
E
8
9
11
12
13
14
15
16
17
B
C
D
E
F
ROUTE SENSOR AND AUXILIARY WIRES
THROUGH THIS KNOCKOUT ONLY
HWRQ
Platinum
INPUTS
T
A1
SYSTEM
TEMP
A2
TO SENSOR TERMINALS
A3
SHUTDOWN
A4
ALL SENSORS MUST BE
GOLD SERIES SENSORS
A5
PROVE
A6
ADJUST
A7
NETWORK
A8
A9
DHW
PRESS TO
CAL
SELECT
A10
T
A11
OUT
TEMP
A12
BACK
A13
T
AUX
TEMP 0
A14
A15
T
AUX
TEMP 1
A16
T
A17
AUX
TEMP 2
A18
F
G
H
18
19
20
21
22
G
H
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for heat-timer HWRQ Platinum
Summary of Contents for heat-timer HWRQ Platinum
- Page 1 MADE IN U S A WARNING This Heat-Timer control is strictly an operating control; it should never be used as a primary limit or safety control. All equipment must have its own certified limit and safety controls required by local codes.
-
Page 2: Table Of Contents
MAC Address Control Logic MODBUS Baud Sensor Fault HWRQ Platinum MODBUS Variable List Day Light Saving Troubleshooting Date and Time Setting Piping and Wiring Diagrams System Settings Warranty Season Specifications Set Point Target Offset HWRQ Platinum Installation and Operation Manual... -
Page 3: Hwrq Panel Layout
Heat optional Run-On Green Earth BYPASS position overrides Ground screw outputs so the burners are always active * DRY CONTACT ONLY ** Only available with the Remote Communications package HWRQ Platinum Installation and Operation Manual... -
Page 4: Extension Panel Layout
- + + - + + NEUTRAL LINE SAFETY GROUND MUST BE CONNECTED MADE IN U S A Burner Modulating Green Earth 120VAC Outputs Not used Ground screw Power with the HWRQ * DRY CONTACT ONLY HWRQ Platinum Installation and Operation Manual... -
Page 5: Understanding Operation Concept
Reset Ratio is Presented as Outdoor Temp. to Water Temp. Ratio In that case, system temperature must not go below such temperature Water Offset HWRQ Platinum Installation and Operation Manual... -
Page 6: Space Feedback Concept
175°F 180 - (1)THR 171 to 174°F 170°F 180 - (2)THR 166 to 169°F A,B,C 165°F 180 - (3)THR A,B,C A,B,C 161 to 165°F A,B,C None A,B,C,D 160°F 180 - (4)THR A,B,C,D None A,B,C,D HWRQ Platinum Installation and Operation Manual... -
Page 7: Initial Pilot Program
PID or Oversize (Control Logic) • T he HWRQ Platinum can use an algorithm (PID) to look at the rate of change in the System. If the System Temperature changes quickly, the HWRQ Platinum will turn on or off stages quickly. If the temperature changes are slow or minor, the HWRQ Platinum will react slowly. The PID logic provides the most stable operation. Stages are brought on or off based on the rate of change of the System Temperature and the impact a stage has on that rate. • F or applications where the stages are oversized for most load conditions, the HWRQ Platinum has Oversize System logic. The Oversize logic turns stages on or off proportionally, based on how far the System Temperature is from the Set Point. Water Offset The Offset value moves the starting point of the Reset Ratio curves. Therefore, any change made to the Offset will immediately change the value of the Target Water Temperature (TGT) by the same amount. For example, if the Target Water Temperature (TGT) was 150°F based on the specific outdoor temperature and Reset Ratio, then increasing the Offset from 0°F to 10°F would increase the Target Water Temperature (TGT) to 160°F. In a new installation, start with an Offset value of 0°F. Adjust the Offset value in mild weather. If the ambient indoor temperatures are too warm in the mild weather, decrease the Offset. If the ambient building temperatures are too cold in the mild weather, increase the Offset. The rule of thumb for baseboard radiation is to change the Offset by 4°F for every 1°F degree you wish to change the building temperatures. For radiant heat applications, change the Offset by 1° or 2° for every degree you wish to change the building temperature. The Offset can be set from -40 to 40°F. Setback Whenever the Outdoor temperature (OD) falls below the Outdoor Cutoff, the system pump is activated and the HWRQ Platinum regulates the heating system to hold the Computed Water temperature. As the Outdoor temperature (OD) changes, the HWRQ Platinum adjusts the actual water temperature to hold a constant Day (Normal) heat level. The Day heat level is for when occupants are present and active. The HWRQ can also hold a lower or Night (Setback) heat level. This lower level of heat is for when the building is unoccupied or tenants are sleeping. The HWRQ has the capability of programming up to 4 Day and 4 Night settings for each day of the week. When the building comes out of Night setting, there is an optional Boost setting to quickly bring the building up to comfortable temperatures. HWRQ Platinum Installation and Operation Manual... - Page 8 • I f the domestic hot water is set to have priority, the system Pump relay will turn off for up to an hour or until the DHW Call terminates, whichever is sooner. Upon termination of DHW Call, the HWRQ Platinum will revert to its operating schedule and logic. Schedules • B y setting an operating Schedule and Night Setback, you can save energy while providing comfortable heat to the building. The setting allows the HWRQ Platinum to reduce Target temperature (TGT) by a specific number of degrees set by the Night Setback during the night or when building is unoccupied, i.e. office buildings and schools. • D uring the day, Day Time settings will change Target temperature (TGT) based on Outdoor temperature (OD), Water Offset, Reset Ratio. A Night Time setting will reduce the Target Temperature by the Setback setting. Each weekday can have up to 4 Day Time and 4 Night Time (Setback) settings. Refer to Schedules (menu selection), and System Settings/System Settings 2/Night Setback (menu selection). Boost • T his feature lets the HWRQ Platinum bring the building up to temperature quickly after a Night Setback. When the HWRQ Platinum HWRQ Platinum Installation and Operation Manual...
-
Page 9: Making Sure You Have The Right Control
Setback. Refer to System Settings/System Settings 2/Boost Mode (menu selection) System Pump Run-On • T his feature lets the HWRQ Platinum run the System Pump for a longer period after the boilers have been turned off, consequently, dissipating the excess heat from the boilers combustion chamber. That way the boiler should not over heat and activate its high limits. Refer to System Settings/Sys Run-On (menu selection) Remote Communication • T he HWRQ Platinum can be upgraded to Internet, BACnet IP, BACnet MSTP, or MODBUS communication to monitor and control all HWRQ Platinum functions from a remote location. Only, the Internet communication package upgrade allows the HWRQ Platinum to accept additional sensors, to monitor their status, and to provide alarms if the sensor values are not in the correct range. MAKING SURE YOU HAVE THE RIGHT CONTROL If you need the HWRQ Platinum to do additional tasks that either is not listed or do not know how to configure them, contact Heat- Timer Corp. Sales Department either by Phone (973)575-4004, Fax (973) 575-4052, or by E-mail support@heat-timer.com. HWRQ Platinum Installation and Operation Manual... -
Page 10: Installation
• A way from excessively high or low temperatures • A t eye level, or where the displays are easily visible • T he surface must be strong enough to hold the weight of the control and the metal enclosure. • L eave 12" of clearance under the enclosure to allow access to gutter cover screws. Remove the HWRQ Platinum from the metal enclosure • R emove the top center screw holding the panel to the enclo- sure. Wiring • L oosen the two screws at the bottom of the enclosure. Knockouts • M ake sure to unscrew any enclosure cables. (Primarily used to connect to computers and remote systems.) -
Page 11: Remote Communication Wiring
• T he RS485 cable must use the Platinum control’s enclosure RS485 Cable RS485 (B) bottom right side knockout. • C onnect the MSTP cable coming from the BACnet MSTP network to the RS485 (A) communication socket on the back Motherboard of the control’s Communication Board. The terminals are labeled ‘A (+)’, G (Ground), and ‘B (-)’. • C onnect the RS485 to the back of the Platinum control’s BACnet Communication Board. Back side of Platinum Control • U se 18# Twisted Pair cable. The cable length must not exceed 3500 feet. • T he ground RS485 terminal (G) MUST be connected to the BMS RS485 Ground. HWRQ Platinum Installation and Operation Manual... -
Page 12: Sensor Installation
Determining the proper location for the Outdoor Sensor is very important The HWRQ Platinum will base the heat on the outdoor temperature information it receives from this location If the sensor is in the sun, or covered with ice, its... -
Page 13: Wiring
• W hen wiring several multi-stage units, start with the lower stage of the first unit and wire it to Output A, followed by the higher stage of the same unit and wire it to Stage B. • S et the Burner Type to any of the multi-stage options. See “Burner Type” on page 21. ALERT Each relay is rated at 1 amp inductive, 6 amps resistive at 120V The total output of all relays must not exceed 15A HWRQ Platinum Installation and Operation Manual... -
Page 14: Wiring The Inputs
PRESS TO PUMP selects boiler menus or next boiler SELECT selects next day Outdoor Sensor steps through output status TEMP HWRQ Platinum Installation and Operation Manual Sensor Shield ROUTE SENSOR AND AUXILIARY WIRES BACK THROUGH THIS KNOCKOUT ONLY TEMP 0 AUTO... -
Page 15: Wiring Dhw Call Input
ALERT TEMP 2 LISTED PUMP 99RA The PROVE input terminals must be shorted for HWRQ Platinum to provide heat DO NOT remove the factory OUTPUT RATINGS: PUMP SAFETY 120VAC, 6A RESISTIVE installed PROVE jumper unless replacing it with a Prove signal... -
Page 16: Wiring To An Extension Panel
WIRING HWRQ PLATINUM TO MULTIPLE EXTENSION PANELS WIRING TO AN EXTENSION PANEL HWRQ PLATINUM PANEL EXTENSION PANEL 1 • T he HWRQ Platinum can control up to 8 stages solely. By adding a Heat-Timer Extension Panel using RS485 Communicatin Board cable, you can add an additional 8 boiler stages. A total RS485 (A) for Remote communication only of two Heat-Timer Extension Panels can be added to Flat Cable Connectors any single HWRQ Platinum totaling 24 boiler stages. plugs to RS485 (B) terminals... -
Page 17: Wiring Wireless Sensors
RS485 Connect to Wireless NM A(+) B(-) CPU Board Platinum Control Motherboard WIRING EXTENSION PANEL LOCKOUT • E ach Extension Panel has 8 Lockout inputs that can be used by the HWRQ Platinum when sequencing the boilers. • T he first Lockout terminals on the first Extension panel will control the first HWRQ Platinum boiler, the boiler that has stage A as its first stage. The second Lockout terminals on the first Extension panel will control the second HWRQ Platinum boiler. • W hen a boiler Lockout terminals are shorted, the HWRQ Platinum will de-energize that boiler stages. In addition, it will omit that boiler from the sequencing process until those terminals are opened again. The display will show L/O under that boiler stages indicating the Lockout Status. HWRQ Platinum Installation and Operation Manual... -
Page 18: Menu Settings
Enter Password: **** --- SENSOR FAULT --- -- DHW SETTING - Stages On CHANGE PASSWORD? No Priority Stages Off Priority - DAY LIGHT SAVING -- FAST COOL DOWN - Enable Minimum Target Temp Disable HWRQ Platinum Installation and Operation Manual... - Page 19 --- LEAD SETTINGS --- Lead Boiler -- MINIMUM RUNTIME-- Rotate Mode Time --- LEAD ROTATION -- Time -- STANDBY DELAY -- Manual FOFO --- LEAD BOILER ---- - LAST STAGE HOLD - 0.0 psi HWRQ Platinum Installation and Operation Manual...
-
Page 20: Setting The Control
Default: °F Fahrenheit SELECT Settings/System Startup/.../Sensor Type • T his option allows you to set the display mode of the sensors and all temperature settings displayed by the HWRQ Platinum. - CONTROL MODE - CONTROL MODE Reset Reset or Set Point Default: Reset Set Point SELECT Settings/System Startup/.../Control Mode • T he HWRQ Platinum can control the water temperature by adjusting it according to Outdoor temperature (Outdoor Reset) or by maintaining an adjustable Set Point. • W hen Reset is selected, the HWRQ Platinum will adjust the Target Water Temperature (TGT) according to the Outdoor Temperature, the Reset Ratio, and the Offset. This option will provide more comfort and fuel savings. HWRQ Platinum Installation and Operation Manual... -
Page 21: Burner Type
• M ax Target SELECT Settings/System Settings/More Settings/Maximum Target -- FAST COOL DOWN - FAST COOL DOWN Minimum Target Temp (Available with Communication Controls only) Min Target Temperature or Off Default: Min Tgt Temp SELECT Settings/System Startup/.../Fast Cool Down • T his option is only available when the HWRQ Platinum has a communication package. HWRQ Platinum Installation and Operation Manual... -
Page 22: Control Logic
Enable SELECT Settings/System Startup/.../Day Light Saving Disable • E nable this feature in areas where Day Light Saving is observed to account for the time changes without having to manually change the time twice a year. DATE AND TIME SETTING ------- SET YEAR ------ Year, Month, Day, Time 2010 YR SELECT Settings/System Startup/.../Set Year • E ntering the correct date and time assures that the HWRQ Platinum will make its changes correctly. • U se the Select and Adjust button to change date and time values. HWRQ Platinum Installation and Operation Manual... -
Page 23: System Settings
(Available with Reset Control Mode Only) -40°F to 40°F Default: 0°F SELECT Settings/System Settings/Target Offset • T he Target Offset setting lets you adjust the starting points of the Reset Ratio curves. This means that, regardless of the Outdoor temperature (OD), or the Reset Ratio that has been selected, when the Offset setting is changed, that change is directly added or subtracted to the Target water temperature (TGT). For example, if the Target water temperature (TGT) was 130°F and the Offset was changed from 0° to 10° (an increase of 10°), then the Target water temperature (TGT) would increase to 140°F • T he Target Offset setting does not change the effect that Outdoor temperature (OD) has on System water temperature (SYS). For instance, with an E setting (1.00 (OD):1.00 (SYS)) Reset Ratio, the System water temperature (SYS) will always increase one degree for each degree change in the Outdoor temperature (OD). What the Offset does is add or subtract a constant temperature value. (See Understanding Operation Concept) • I f required: Adjust the Water Offset in mild weather. If the ambient building temperatures are too warm in the mild weather, decrease the Water Offset. If the ambient building temperatures are too cold in the mild weather, increase the Water Offset. The rule of thumb for baseboard radiation is to change the Offset 4°F for every 1°F you wish to change the building temperatures. In radiant heat applications, change the Offset 1°F or 2°F for every 1°F you wish to change the building temperature. HWRQ Platinum Installation and Operation Manual... -
Page 24: Reset Ratio
• T he Pump relay will energize whenever the Outdoor temperature (OD) is below the Outdoor Cutoff (CUT). When the Outdoor temperature increases 2°F above the Outdoor Cutoff after the last burner stage relay has de-energized, the Pump relay will stay on for a period of time set by the Pump Run-On. This allows the Pump to dissipate the residual heat within the boilers back into the building. • T he Pump Run-On time should be set based on the size and type of the boilers. A boiler with low water content and high horsepower will need a longer Pump Run-On than a boiler with the same horsepower but has more water content. - MIN TARGET TEMP -- MINIMUM TARGET 80 F 70°F to 170°F Default: 80°F SELECT Settings/System Settings/More Settings/Minimum Target • T he Minimum Water Temperature must be set to the boiler manufacturer’s specification. The HWRQ Platinum will calculate the Target temperature (TGT) based on the Outdoor temperature (OD), the Reset Ratio, and the Offset value. The HWRQ Platinum will control the burner stages to hold either the calculated temperature, or the Minimum Water Temperature, whichever is higher. • T he Minimum Target must be at least 20°F lower than the Maximum Target ( See next setting). HWRQ Platinum Installation and Operation Manual... -
Page 25: Maximum Target
• T he HWRQ Platinum will accomplish this by running elevated water temperatures for Manual Boost a given time period based on the #1 Day Time schedule for that day. - BOOST ADJUSTMENT - • I f you do not want a Boost on a day of the week, simply program the #1 Day Time Higher = More Boost schedule to **:**, and use the #2 Day Time program for any Day (Normal) settings. 0min • T o cancel a Boost or Early Shutdown for one time only for a specific day without changing the Schedule, Select Shift from the Settings menu. Any Shifting will result in cancelation of Boost or Early Shutdown. Vari Boost - BOOST ADJUSTMENT - Higher = More Boost HWRQ Platinum Installation and Operation Manual... -
Page 26: Stage Settings
• Rotate Mode REACTION TIME -- REACTION TIME ---- (Available with PID Control Logic Only) 1 minute to 10 minutes Default: 2 minutes SELECT Settings/System Settings/More Settings/Stage Settings/Reaction Time • I t is the amount of time it takes a single stage to affect the system. • A fter the HWRQ Platinum turns on a stage trying to meet a set point, it will not turn on another stage until the reaction time has elapsed. Then, it will recalculate if a stage is need. • T o determine the optimum time, start with a hot system. Then, turn on a single stage and calculate how long it takes until the system begins to respond to that stage. That period should be set as the Reaction Time. HWRQ Platinum Installation and Operation Manual... -
Page 27: Purge Delay
(AvAILABLe wIth PID CONtROL LOgIC ONLy) 0°F to 30°F Default: 5°F SELECT Settings/System Settings/More Settings/Stage Settings/Lst Stage Hold • T he Last Stage Hold prevents short cycling of the Lead Stage during low load conditions. • I n low load conditions, the system might have a load that is significantly less than the output of one Stage. When the HWRQ Platinum brings on the Lead Stage, the Set Point is quickly exceeded, and the HWRQ Platinum turns the Lead Stage off. • T o prolong the run time during this type of condition, use the Last Stage Hold setting. • T he HWRQ Platinum will allow the system temperature to exceed the Set Point by the number of degrees selected, before the Lead Stage is turned off. • F or example, with a Set Point of 160°F and a Last Stage Hold setting of 10°F, the Lead Stage boiler will remain on until the Set Point reaches 170°F then de-energize. HWRQ Platinum Installation and Operation Manual... -
Page 28: Throttle
--- LEAD BOILER ---- A thru H or last boiler number Default: <A> SELECT Settings/System Settings/More Settings/Stage Settings/Lead Boiler or Settings/System Settings/More Settings/Stage Settings/Lead Settings/Lead Stage • T he Lead Boiler’s lowest stage will always be the first stage brought on when there is a call for output. As more output is needed, additional Stages are added. • T he Lead Boiler is shown on the main display in brackets. • I n a 2-Stage system (see Boiler Type in the Startup section), the display will show the two Lead Boiler stages bracketed <AB>. In a 3-Stage system, the display will show the three Lead Boiler stages bracketed <ABC>, and so on. • T he Lead Boiler can be rotated based on the Rotation Mode selected. (See next setting) HWRQ Platinum Installation and Operation Manual... - Page 29 Auto, Standby, Off, On Default: Auto Auto BOILER (Button) Standby By pressing the BOILER button, the Boiler Operation mode menu selection will display. There are four modes. By pressing the BOILER, NEXT, or PREV buttons the display will scroll between the different modes. • A uto - I n this mode boiler stage will operate based on control settings. Boiler can be used in rotation. • S tandby - B oiler will start only after all Boilers set to Auto are on for the full Standby Delay. • O ff - B oiler relay will be Off until this setting is changed. • O n - B oiler relay as well as System relay will be On until this setting is changed. HWRQ Platinum Installation and Operation Manual...
-
Page 30: Schedules
• T he Night Time (Setback) level is used when a building is not occupied, or when Set Date/Time people are sleeping. • T he HWRQ Platinum can have up to four Day Time and four Night Time (Setback) periods for each individual day of the week. The HWRQ Platinum will show which ALERT period is it in on the 2nd line of the display. The HWRQ Platinum will ignore any • E very time the HWRQ Platinum updates the clock time, it checks the Day/Night Time setting that reads **:** program. If there is a matching Day/Night time programmed, it sets the heat level accordingly, otherwise, the heat level is not changed. This means you do not have to The #1 setting for any Day Time is program every day of the week. -
Page 31: Vacation Schedule Setting
ALERT Remember that the battery is the only backup for the Date and Time If no power is supplied to the HWRQ Platinum and there was no battery or battery had no power, date and time values will be lost and will need to be readjusted... -
Page 32: Maintenance
• Enter HWRQ into the Login screen. the Shift to Extend Day and the Auto/ • When completed, select No to the prompt “Change Password?” Bypass switch operation Note: When Password is enabled, all settings will be read only except for the Shift to Extended Day and the toggling of the Auto/Bypass Switch. HWRQ Platinum Installation and Operation Manual... -
Page 33: Shift
ENCLOSED ALERT BYPASS ENERGY When the HWRQ Platinum is switched to Bypass locally or remotely, all stages will MANAGEMENT turn on regardless of the Boiler Mode setting In this case, Sensor Fault, Shutdown, EQUIPMENT and Prove will have no effect on the control operation... -
Page 34: Communication Options
000 . --- . --- . --- 19200 19200 38400 38400 ----- IP ADDRESS ----- 000 . --- . --- . --- --MAC ADDRESS-- ---- MAC ADDRESS --- --BACNET DEVICE ID-- --BACNET DEVICE ID-- HWRQ Platinum Installation and Operation Manual... -
Page 35: Internet Communication Features
Firewall and Router must allow outgoing traffic on port 4133 and incoming traffic on ports 8082 - 8114, ● A Heat-Timer router is required when multiple panels are connected to a single internet connection For custom configurations contact Heat-Timer INTERNET COMMUNICATION - REMOTE INTERFACE - visit (http://www.htcontrols.com) -
Page 36: Internet Id
--- INTERNET ID --- n umber from (1-31). ---.---.---.--- • T he Custom option allows the user to manually configure the Internet connection. Msk: ---.---.---.--- ALERT Gwy: ---.---.---.--- When connecting multiple panels to the Internet, a Heat-Timer Router is required DNS: ---.---.---.--- INTERNET PORT FORWARDING TABLE Platinum Hi Speed Control Modem Internet... -
Page 37: Override Remote Changes
PASSWORD" or "ALL CHANGES of that setting. REQUIRE PASSWORD" has been selected from the Internet • T o take all settings out of override, go the ICMS System Overrides webpage and Maintenance screen select “Remove all Overrides” button. • T o allow an Internet communication control overridden values to be adjusted locally, the Panel Password Mode under the Maintenance live session must be set to either “Only Overrides Require Password” or “All Changes Require Password”. This will allow a control user with the proper password to make changes to overridden settings. • A ll BACnet IP communication controls provide access to change their override values locally when the password is entered. List of HWRQ Platinum Overrides HWRQ Platinum Installation and Operation Manual... -
Page 38: Internet Alarms
◦ ( #1006) System Sensor Fault: This alarm will be generated whenever the System sensor goes open or short. ( #6006) Is an end alarm that can be set to indicate that the initial alarm status has terminated. ◦ ( #1008) No prove for More Than 10 Minutes: This alarm will be generated whenever there is a call for output but the Prove terminals have not been shorted for over 10 minutes.. ( #6008) Is an end alarm that can be set to indicate that the initial alarm status has terminated. ◦ ( #1012) The DHW-ES (Purchased separately) was activated but had no communication for over 1 minute. ( #6012) Is an end alarm that can be set to indicate that the initial alarm status has terminated. ◦ ( #3000) The Platinum control could not establish a dependable two way communication with the Heat-Timer Servers for over 24 hours. ( #8000) Is an end alarm that can be set to indicate that the initial alarm status has terminated. HWRQ Platinum Installation and Operation Manual... -
Page 39: Bacnet Communication
Baud: 9600 system. The gateway used must have both drivers, the BACnet IP or MSTP and the Switch to IP proprietary protocol. BACNET DEVICE ID --BACNET DEVICE ID-- • T his is a 32 bit unique number within the BACnet network. It identifies the Platinum control within the BACnet network. It must be provided by the BACnet Network Administrator and entered into the BACnet ID field. MS/TP ADDRESS/ MAC ADDRESS --MAC ADDRESS-- • T his is the MSTP or MAC address on a RS485 network. Its MSTP range is 1 though 127. • T he MS/TP address must be provided by the Network Administrator. HWRQ Platinum Installation and Operation Manual... -
Page 40: Mstp Baud Rate)
-3 - +3°C, -5 - +5°F Trim 2400 OFFSET Offset Temp °C(62), °F(64) -22 - +22°C, -40 - +40°F 2500 PDATE Panel Date Days (70) since 0 - 2,147,483,647 1/1/1981 2600 PRUNON Pump Run-On Minutes(72) 0 - 60 HWRQ Platinum Installation and Operation Manual... - Page 41 Note: The HWRQ Platinum has a schedule, which is 7-days, 4 day/night pairs per day For example: Instance 3400 is the first DAY schedule of Monday; Instance 3401 is the first NIGHT schedule of Monday; Instance 3408 is the first DAY schedule of Tuesday;...
-
Page 42: Bacnet Pics Statement
Address and Phone Heat-Timer Corporation 20 New Dutch Ln Fairfield, NJ 07004 - (973)575-4004 Product Description HWRQ Platinum control for hot water heating applications (see http://www heat-timer com for more information) BACnet Standardized Device Profile (Annex L) Product Device Profile... -
Page 43: Modbus Rtu Communication Configuration
0=No Priority, 1= Priority Day Light Saving 0=Enable, 1=Disable Sensor Fault Mode 0=Stages On, 1=Stages Off Fast Cool Down 0=Minimum Target Temp, 1=Off Sensor Type 0=°F Sensor, 1=°C Sensor Lead Boiler (Refer to Table 2) HWRQ Platinum Installation and Operation Manual... - Page 44 0 - 116°C, 0 – 240°F(32003 - Calculated Target °C, °F Off) ♦2 'Throttle Range' Range °C, °F 1 – 11°C , 2 - 20°F Max Target Temp °C, °F 32 – 116°C, 90 – 240°F HWRQ Platinum Installation and Operation Manual...
- Page 45 Use 'Max Target' when 'Control Mode' is set to 0 Note: The HWRQ Platinum has a schedule, which is 7-days, 4 day/night pairs per day For example: Register 38 is the first DAY schedule of Monday; Register 39 is the first NIGHT schedule of Monday; Register 46 is the first DAY schedule of Tuesday;...
-
Page 46: Troubleshooting
3667 2914 To perform the test, you will need a digital multi-meter capable of reading resistances. The Heating 2332 System Sensor and Outdoor Sensor temperatures are constantly displayed on the HWRQ Platinum. 1879 Remove the outdoor sensor wires from the Out Temp terminals (A11 and A12), or the heating system sensor wires from System Temp terminals (A1 and A2). Use the multi-meter to take a resistance 1524 reading across the detached wires going to the sensor. If the reading shows: 1243 1021 • O PEN or resistance is higher than the values on the adjacent chart - Check the wires going to the sensor. They may have been broken or become disconnected. If the wires are fine, check the resistance at the sensor itself. If the resistance is still open, the sensor has been damaged and needs to be replaced. • S HORT or resistance is lower than the values on the adjacent chart - Check the wires going to the sensor. They may have become shorted together in the run of the wire. If not, check the resistance at the sensor itself. If there still is no resistance, the sensor has been damaged and needs to be replaced. • R esistances from 187 ohms to 117720 ohms - Find the temperature that corresponds to the resistance value on the chart. If the sensor appears to be outputting correctly, check that the wires were properly connected to the HWRQ Platinum inputs. If the sensor is not outputting correctly, take another reading at the sensor itself. If this is correct, the problem is in the wiring SHORT between the sensor and the HWRQ Platinum. Otherwise, the sensor has been damaged, and should be replaced. HWRQ Platinum Installation and Operation Manual... -
Page 47: Piping And Wiring Diagrams
Heat ALERT Since each installation is unique, Heat-Timer Corp is not responsible for any installation related to any electrical or piping diagram generated The provided illustrations are to demonstrate the control operating concept only HWRQ Platinum Installation and Operation Manual... - Page 48 HWRQ Platinum Installation and Operation Manual...
- Page 49 Pump ALERT Since each installation is unique, Heat-Timer Corp is not responsible for any installation related to any electrical or piping diagram generated The provided illustrations are to demonstrate the control operating concept only HWRQ Platinum Installation and Operation Manual...
- Page 50 HWRQ Platinum Installation and Operation Manual...
- Page 51 Pump ALERT Since each installation is unique, Heat-Timer Corp is not responsible for any installation related to any electrical or piping diagram generated The provided illustrations are to demonstrate the control operating concept only HWRQ Platinum Installation and Operation Manual...
- Page 52 HWRQ Platinum Installation and Operation Manual...
- Page 53 Pump ALERT Since each installation is unique, Heat-Timer Corp is not responsible for any installation related to any electrical or piping diagram generated The provided illustrations are to demonstrate the control operating concept only HWRQ Platinum Installation and Operation Manual...
- Page 54 HWRQ Platinum Installation and Operation Manual...
- Page 55 HWRQ Platinum Installation and Operation Manual...
- Page 56 HWRQ Platinum Installation and Operation Manual...
- Page 57 HWRQ Platinum Installation and Operation Manual...
- Page 58 HWRQ Platinum Installation and Operation Manual...
-
Page 59: Warranty
WARRANTY WARRANTIES AND LIMITATIONS OF LIABILITY AND DAMAGE: Heat-Timer Corporation warrants that it will replace, or at its option, repair any Heat-Timer Corporation manufactured product or part thereof which is found to be defective in material workmanship within one year from the date of installation only if the warranty registration has been properly filled out and returned within 30 days of the date of installation. Damages to the product or part thereof due to misuse, abuse, improper installation by others or caused by power failure, power surges, fire, flood or lightning are not covered by this warranty. Any service, repairs, modifications or alterations to the product not expressly authorized by Heat-Timer Corporation will invalidate the warranty. Batteries are not included in this warranty. This warranty applies only to the original user and is not assignable or transferable. Heat-Timer Corporation shall not be responsible for any maladjustments of any control installed by Heat-Timer Corporation. It is the users responsibility to adjust the settings of the control to provide the proper amount of heat or cooling required in the premises and for proper operation of the heating or cooling system. Heat-Timer Corporation shall not be required to make any changes to any building systems, including but not limited to the heating system, boilers or electrical power system, that is required for proper operation of any controls or other equipment installed by Heat-Timer Corporation or any contractor. Third Party products and services are not covered by this Heat-Timer Corporation warranty and Heat-Timer Corporation makes no representations or warranties on behalf of such third parties. Any warranty on such products or services is from the supplier, manufacturer, or licensor of the product or service. See separate Terms and Conditions of Internet Control Management System (“ICMS”) services, including warranties and limitations of liability and damages, for ICMS services. THE FOREGOING IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED AND HEAT-TIMER CORPORATION SPECIFICALLY DISCLAIMS ANY AND ALL WARRANTIES OF MERCHANTABILITY FOR A PARTICULAR PURPOSE. UNDER NO CIRCUMSTANCES SHALL HEAT-TIMER CORPORATION, ITS AUTHORIZED REPRESENTATIVES, AFFILIATED OR SUBSIDIARY COMPANIES BE LIABLE FOR SPECIAL, CONSEQUENTIAL OR INCIDENTAL DAMAGES, EXCEPT AS SPECIFICALLY STATED IN THESE TERMS AND CONDITIONS OF SALE. THE SOLE REMEDY WITH RESPECT TO ANY PRODUCT OR PART SOLD OR INSTALLED BY HEAT-TIMER CORPORATION SHALL BE LIMITED TO THE RIGHT TO REPLACEMENT OR REPAIR F.O.B. FAIRFIELD, NJ. HEAT-TIMER CORPORATION SHALL NOT BE LIABLE OR RESPONSIBLE FOR LOSS OR DAMAGE OF ANY KIND RESULTING FROM DELAY OR INABILITY TO DELIVER FOR ANY REASON, INCLUDING BUT NOT LIMITED TO FIRE, FLOOD, LIGHTNING, POWER FAILURE OR SURGES, UNAVAILABILITY OF PARTS, STRIKES OR LABOR DISPUTES, ACCIDENTS AND ACTS OF CIVIL OR MILITARY AUTHORITIES. 03122010 HWRQ Platinum Installation and Operation Manual... -
Page 60: Specifications
