Ets Duplex - heat-timer ETS Installation And Operation Manual

Figure 2: ETS Duplex (ETS‐30 or ETS‐40) Controls, Indicators, and Connections
6
5
Item
1 Electronic Temperature Controller
(ETV Platinum Plus)
2 Disconnect Box with Transformer and Audible Alarm
3 Temperature Gauge
4 ETV Valve Body with Actuator
5 Motorized Safety Valve
Heat‐Timer Corp.
9
8
7
Description
Controls, Indicators, and Connections 5
10
1
2
3
4
Item Description
6 Hot Water Line
7 Boiler Feed Line
8 Cold Water Line
9 Recirculation Water Line
10 Tempered Water Line
059326‐00 Rev D
