ADS131B26Q1EVM-PDK Bill of Materials, PCB Layout, and Schematics

7.2 PCB Layout

Figure 7-1 through Figure 7-6 show the ADS131B26Q1EVM-PDK PCB layout.

Figure 7-1. Top Silkscreen

Figure 7-3. Ground Layer

Figure 7-5. Bottom Layer

28 ADS131B26Q1EVM-PDK Evaluation Module
Copyright © 2022 Texas Instruments Incorporated

Figure 7-2. Top Layer

Figure 7-4. Power Layer

Figure 7-6. Bottom Silkscreen
