Diagnostics

10.1.2. Event Log

Figure 44. Event log page example
How To Analyze the Information
The log follows the FIFO principle, first in and first out. The oldest (first) value is processed first.
Time (d:hh:mm:ss.ms)
Message
Severity
Source
To clear the current log, click Clear log.
SCM-1202-202 Version 1.0
The date and time when the event occurred.
A brief description of the event.
The severity of the event occurred.
For description of the symbols, see Communicator Status
0 Communicator
1 PROFIBUS
2 PROFINET
® ™
Anybus Communicator - PROFINET Device to PROFIBUS Device
Monitor.
