DIN Rail Demount
5.9. DIN Rail Demount
Before You Begin
IMPORTANT
Be careful when removing the Communicator from the DIN-rail. If not removed properly, the DIN rail
locking mechanism and the product cover can break.
Have a flat-blade screwdriver, size 5.5 mm, available.
Procedure
Remove the Communicator from the DIN Rail:
1.
Insert the screwdriver into the Communicator DIN rail locking mechanism.
2.
To unlock the Communicator DIN rail locking mechanism, turn the screwdriver clockwise.
Figure 14. Unlock the Communicator
SCM-1202-202 Version 1.0
®
™
Anybus
Communicator
- PROFINET Device to PROFIBUS Device
Page 21 of 60
