SWITCHBACK 2-LEG 2-STAGE ASSEMBLY INSTRUCTIONS
3
C-LEG
4
C-LEG
Cross-brace
U-pipe
STEPS
3. Install one M6 × 8 mm screw on the opposite side using the 5 mm hex L-key.
4. Insert U-pipe into cross-braces.
M6 × 8 mm Screw
To report any issues with this product, please contact our customer service department at (888) 274-8664.
For more information, visit www.sitonit.net
T-LEG
T-LEG
Cross-brace
U-pipe
M6 × 8 mm Screw
5
