SWITCHBACK 2-LEG 2-STAGE ASSEMBLY INSTRUCTIONS

C-LEG

T-LEG

STEPS

2. Place the top supports onto the assembly as shown. The flange on the top supports will be inserted into the

rectangular tube end. Install one M6 × 16 mm screw through each rectangular tube and top support flange into

the motor housing and tighten using the 5 mm hex L-key.

M6 × 16 mm Screw

Column

Cross-brace

To report any issues with this product, please contact our customer service department at (888) 274-8664.

For more information, visit www.sitonit.net

Column

Top Support
