1.0 GENERAL SPECIFICATIONS

Electrical requirements:
115V model
230V model
Fuse
Speed
Shaker Orbit
Timer
Maximum Load
Dimensions WxLxH
Platform dimensions WxL
Weight
Operating Conditions

2.0 INSTALLATION OF THE SHAKER

2.1 UNPACKING

Before starting the installation, carefully examine the shaker for possible damage or
missing parts.
- Open the box and carefully remove the padding. Check that the shaker has
not been visibly damaged during transportation. Keep the packing material
until you are sure that the shaker works properly.
- Carefuly lift the device out of the box.
- Be sure that the following information is included on the serial label located
on the back of the unit: Serial Number, Product number, Electrical rating.
- Check that the power cord has a pin configuration that fits into a wall socket
according to the local standard.
Should any kind of damage have occurred during transportation, contact the carrier
immediately. The carrier is responsible for shipping damage.

2.2 SELECTING THE CORRECT LOCATION

When locating the shaker, please consider following:
- Put the shaker on horizontal, leveled and stable surface.
- Leave enough space around the shaker for normal air circulation, min. 10 cm.
- Leave enough space around the shaker for easy access and maintenance.
- Avoid locations subject to shocks and vibrations.
- Avoid locations subject to frequent power fluctuations or power losses (It may
affect shaker performance)
Note: There has to be an easy access to the shaker control panel and main plug in case of
emergency

2.3 ATTACHING THE POWER CORD

First connect the main power cord to the shaker then connect the plug end of the cord to a
grounded wall socket. Avoid lines on which powerful electric motors, refrigerators and
similar devices are connected.
Be careful when you plug the cord to a grounded wall socket!
Do not touch plug with wet hand!
115V ± 10% - 50/60Hz, 0.3A
230V ± 10% - 50/60Hz, 0.15A
2 x 0.5A 230V ; 2 x 1A 115V
from 3 to 60 rpm
19 mm (3/4 inch)
20 – 120 min in 10 min step, HOLD function
5 kg
295x340x160mm
295x295mm useable area
6.6 kg
4°C to 70°C, up to 85% RH, non-condensing
