AD9776A/AD9778A/AD9779A
Register
Register Name Address
AUX DAC2 Control 0x12
0x11
0x12
0x12
0x12
0x13 to
0x18
Interrupt 0x19
0x19
0x19
0x19
0x19
0x19
Version 0x1F
Bits Parameter
1:0 Auxiliary DAC2 Data[9:8]
7:0 Auxiliary DAC2 Data[7:0]
7 Auxiliary DAC2 sign
6
Auxiliary DAC2 current
direction
5 Auxiliary DAC2 power-down
Reserved
7 Data timing error IRQ
6 Sync timing error IRQ
4 Data timing error type
3 Data timing error IRQ enable
2 Sync timing error IRQ enable
0 Internal sync loopback
7:0 Version[7:0]
Rev. B | Page 32 of 56
Function
Auxiliary DAC2 Data[9:0] is the 10-bit output
current control word. Magnitude of the auxiliary
DAC current increases with increasing value. Bit 9 is
the MSB and Bit 0 is the LSB.
0: AUX2_P active.
1: AUX2_N active.
0: source.
1: sink.
0: auxiliary DAC2 on.
1: auxiliary DAC2 off.
Read only. Active high indicates a timing violation
occurred on the input data port. The IRQ is latched.
This bit is cleared when the Interrupt register is read.
Read only. Active high indicates a timing violation
occurred on the SYNC_I input. The IRQ is latched.
This bit is cleared when the Interrupt register is read.
Read only. Indicates the timing error type.
0: hold time violation.
1: setup time violation.
Meaningful when data timing error IRQ is active.
0: data timing error IRQ is masked.
1: data timing error IRQ is enabled.
0: sync timing error IRQ is masked.
1: sync timing error IRQ is enabled.
The received SYNC_O signal is looped back to the
SYNC_I signal.
Indicates device hardware revision number.
Default
00
00000000
0
0
0
0
0
0
0
0
0
00000111
