Omron MicroHAWK V320-F Series User Manual page 154

Appendices
32 bit
32 bit
A-30
Autofocus Multicode Reader MicroHAWK V320-F/V330-F/V420-F/V430-F Series User Manual for Communication Settings (Z407-E1)
Member Name
UserTag_21
UserTag_22
UserTag_23
UserTag_24
UserTag_25
UserTag_26
UserTag_27
UserTag_28
UserTag_29
UserTag_30
UserTag_31
UserTag_32
Commands
Trigger
New Master
Reserved
Disable Scanning
Reserved
Clear Read Cycle Report and
Counters
Unlatch Outputs
Reserved
External Output
Output 1
Output 2
Output 3
Reserved
Data Type Bit Number
20
21
22
23
24
25
26
27
28
29
30
31
DINT
0
1
2 - 7
8
9 - 15
16
17
18 - 31
DINT
0
1
2
3 - 31
Data Length Byte Offset
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
4 Byte 4
1 bit
1 bit
6 bit
1 bit
7 bit
1 bit
1 bit
14 bit
4 Byte 8
1 bit
1 bit
1 bit
29 bit
