3 Controlling Operation and Data Output with Ethernet
Category
Device Con-
trol
Counters and
Counter Re-
sets
3-44
Autofocus Multicode Reader MicroHAWK V320-F/V330-F/V420-F/V430-F Series User Manual for Communication Settings (Z407-E1)
Command
<L1> Parallel OUTPUT 1 Signal turns ON.
<L2> Parallel OUTPUT 2 Signal turns ON.
<L3> Parallel OUTPUT 3 Signal turns ON.
<l1> Turn ON the target pattern (blue LED).
<l0> Turn OFF the target pattern (blue LED).
<I> Disables Read Cycle. While Read Cycle is
Disabled, it cannot accept a trigger.
<H> Enables Read Cycle.
<q> Gets the number of No Reads in the Read Cy-
cle. The Response data output is q/ followed
by a 9 digit value for the number of No Read.
<q0> Clears the number of No Reads in the Read
Cycle.
<$> Gets the Mismatch Count. The Response data
output is $/ followed by a 9 digit value for the
number of Mismatch.
<$0> Clears the Mismatch Count.
<N> Gets the number of No Reads. The Response
data output is N/ followed by a 9 digit value for
the number of No Reads
<O> Clears the Mismatch Count.
<T> Gets the Trigger Input Count. The Response
data output is T/ followed by a 9 digit value for
the number of Triggers.
<U> Clears the Trigger Input Count.
<V> Gets the Match Count when the Matchcode
function is used. The Response data output is
V/ followed by a 9 digit value for the number of
Matched strings.
<W> Clears the Match Count.
<X> Gets the Mismatch Count when the Match-
code function is used. The Response data
output is X/ followed by a 9 digit value for the
number of Mismatched strings.
<Y> Clears the Mismatch Count.
Description
Response Data Example
(For Read string ABCDE.)
None
None
None
None
None
None
None
<q/000000005>
None
<$/000000002>
None
<N/000000005>
None
<T/000000010>
None
<V/000000010>
None
None
