Omron V330-F Series Connection Manual

Auto focus multi code reader
Hide thumbs Also See for V330-F Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Programmable Controller CJ-series
EtherNet/IP
OMRON Corporation
Auto Focus Multi Code Reader
V330-F / V430-F-series
Connection Guide
TM
Z413-E1-01

Advertisement

Table of Contents
loading

Related Manuals for Omron V330-F Series

Summary of Contents for Omron V330-F Series

  • Page 1 Programmable Controller CJ-series EtherNet/IP Connection Guide OMRON Corporation Auto Focus Multi Code Reader V330-F / V430-F-series Z413-E1-01...
  • Page 2 About Copyrights and Trademarks Microsoft product screen shots used with permission from Microsoft. Windows is a registered trademark of Microsoft Corporation in the USA and other countries. ODVA, EtherNet/IP are trademarks of ODVA. Company names and product names in this document are the trademarks or registered trademarks of their respective companies.

  • Page 3: Table Of Contents

    Contents Related Manuals ..................3 Terms and Definitions ................4 Restrictions and Precautions ..............5 Overview ....................6 Applicable Devices and Device Configuration ........7 5.1. Applicable Devices ................7 5.2. Device Configuration ................8 EtherNet/IP Settings ................. 11 6.1. Parameters ..................

  • Page 4: Related Manuals

    To ensure system safety, make sure to read and follow the information provided in all Safety Precautions and Precautions for Safe Use in the manuals for each device which is used in the system. The following OMRON Corporation (hereinafter referred to as “OMRON”) manuals are related to this document: Cat. No.

  • Page 5: Terms And Definitions

    2. Terms and Definitions 2. Terms and Definitions Below is a list of terms used in this manual and their definitions. Term Description/Definition Node It refers to a relay point, a branch point or a terminal on an EtherNet/IP network comprised of equipment having an EtherNet/IP port. Devices with one EtherNet/IP port are recognized as one node on the EtherNet/IP network, and devices with two EtherNet/IP ports are recognized as two nodes.

  • Page 6: Restrictions And Precautions

    (4) It is prohibited to copy, to reproduce, and to distribute a part or the whole of this document without the permission of OMRON Corporation. (5) The information contained in this document is current as of July 2022.

  • Page 7: Overview

    4. Overview 4. Overview This document describes the procedures for connecting the OMRON code reader products (V330-F/V430-F Series) to a CJ Series Machine Automation Controller + EtherNet/IP Unit (PLC) via EtherNet/IP and for checking their connections. Refer to Section 6. EtherNet/IP Settings and Section 7. EtherNet/IP Connection Procedure to understand setting methods and key points to operate EtherNet/IP tag data links.

  • Page 8: Applicable Devices And Device Configuration

    It also does not describe the function or operation of the equipment. Refer to the manuals or contact your OMRON representative. Note This document describes the procedures for establishing the communication connection of the device, and does not describe the operation, installation and wiring method of the device.

  • Page 9: Device Configuration

    LAN cable LAN cable LAN cable USB cable PoE injector LAN cable 24 VDC power supply Manufacturer Name Model Version OMRON CJ Series CPU Unit CJ2M-CPU11 Ver. 2.0 OMRON EtherNet/IP Unit CJ1W-EIP21 Ver. 2.1 OMRON Power Supply Unit CJ1W-PA202 OMRON...
  • Page 10 V430-W8□ Ethernet cable V430-WE□ USB cable LAN cable 24 VDC power supply 24 VDC power supply Manufacturer Name Model Version OMRON CJ Series CPU Unit CJ2M-CPU11 Ver. 2.0 OMRON EtherNet/IP Unit CJ1W-EIP21 Ver. 2.1 OMRON Power Supply Unit CJ1W-PA202 OMRON...
  • Page 11 5. Applicable Devices and Device Configuration Precautions for Correct Use Ensure that the CX-Programmer and Network Configurator are updated to the versions specified in this section or higher. If you use a version other than the version specified in this section, there may be differences in the procedures in Section 7 and later.

  • Page 12: Ethernet/Ip Settings

    6. EtherNet/IP Settings 6. EtherNet/IP Settings This section shows the specifications of the parameters and tag sets that you set in this document. 6.1. Parameters The parameters that you set in this document are shown below. 6.1.1. EtherNet/IP Communication Settings The parameters used for connecting the controller and the code reader via EtherNet/IP are as follows.

  • Page 13: Assigning Tag Data Links

    6. EtherNet/IP Settings 6.2. Assigning Tag Data Links This section describes how to assign tag data links for the code reader. It shows the tag data link assignments with the following assemblies. • Input Assembly: 1 Decode Input Assembly (103) •...
  • Page 14 6. EtherNet/IP Settings ■ Input Area Description Address Description 15 14 13 12 11 10 9 D11000 RESERVED INFO_BITS INFO BIT Reserved for future RESERVED RESERVED D11001 D11002 Code Reader Signal DEVICE STATUS D11003 Status Information D11004 Code Reader Error FAULT D11005 Code Information...

  • Page 15: Ethernet/Ip Connection Procedure

    7. EtherNet/IP Connection Procedure 7. EtherNet/IP Connection Procedure This section describes the procedures for connecting the code reader and the PLC on an EtherNet/IP network. In this document, it is assumed that the PLC and the code reader use the factory default settings.

  • Page 16: Code Reader Setup

    7. EtherNet/IP Connection Procedure 7.2. Code Reader Setup Set up the code reader. 7.2.1. Setting the Parameters Set the parameters for the code reader. Set the IP address of your PC to 192.168.188.100 and its subnet mask to 255.255.0.0. [Using V330-F] Switching hub V330-F064N12M-NNX Connect the cord reader and the...
  • Page 17 7. EtherNet/IP Connection Procedure Set the IP Address of the PC. For the IP address, enter 192.168.188.100. For the subnet mask, enter 255.255.255.0. For the procedure to open the screen on the right, please refer to step 4. Static connection (Setting the fixed IP address) (1) From the Windows Start Menu, select Control Panel –...
  • Page 18 7. EtherNet/IP Connection Procedure If the WebLink startup screen does not appear, it means that communications are not established between the code reader and the PC. Please check the following. • Does the code reader and the PC have a proper physical (cable) connection? •...
  • Page 19 7. EtherNet/IP Connection Procedure The Advanced Settings Screen appears. Check the settings shown in the red frames. EtherNet/IP connection is Enabled by default. However, to connect with the CJ Series, change the subnet mask to 255.255.255.0 . If you need to change the IP address, for example when connecting multiple code readers, change the IP Address...
  • Page 20 7. EtherNet/IP Connection Procedure Finally, check the version number of the code reader. Click on the gear icon on the upper right of the screen and select About WebLink. Check the current version of the code reader in About WebLink. Make sure that 2.1.0 or later version is shown in the red frame.

  • Page 21: Plc Setup

    7. EtherNet/IP Connection Procedure 7.3. PLC Setup Set up the PLC. 7.3.1. Setting the Hardware Set up the physical switches on the EtherNet/IP Unit and perform wiring for network connection. Precautions for Correct Use Turn OFF the power supply before setting the hardware. Check that the power supplies to the PLC, code reader, and switching hub are OFF.
  • Page 22 7. EtherNet/IP Connection Procedure Set the Node address switches to the default values as follows. NODE No. X16 NODE No. X16 * Set the IP Address to 192.168.188.1. * By default, the first three octets are fixed to “192.168.188”. The value set by the Node address switches determines the fourth octet of the node’s IP address.
  • Page 23 7. EtherNet/IP Connection Procedure 7.3.2. Starting the CX-Programmer and Going online with the PLC Start the CX-Programmer and go online with the PLC. Install the CX-One and USB driver on the PC beforehand. Start the CX-Programmer. * If a user account control dialog box is displayed at startup, select the option to start.
  • Page 24 7. EtherNet/IP Connection Procedure A confirmation dialog box as shown in the figure on the right appears. Read the information and click No. A dialog box as shown in the figure on the light appears and auto connection is performed. Confirm that the CX-Programmer is online with the PLC.
  • Page 25 7. EtherNet/IP Connection Procedure 7.3.3. Creating the I/O Table and Setting the IP Address Create the I/O table for the PLC and set the IP address. If the PLC Operating Mode is set to either Run or Monitor, follow steps (1) to (3) to change it to Program.
  • Page 26 7. EtherNet/IP Connection Procedure Precautions for Correct Use Performing I/O Table creation and transfer in step 3 and later resets the PLC. Confirm the system safety before you perform I/O Table creation and transfer. In the PLC IO Table Window, select Create from the Options Menu.
  • Page 27 7. EtherNet/IP Connection Procedure The Transfer from PLC Dialog Box is displayed. Select the check boxes for IO Table and SIO Unit Parameters and click Transfer. When the transfer is complete, the Transfer Results Dialog Box appears. Check the messages in this dialog box to confirm that the transfer process is successfully completed.
  • Page 28 7. EtherNet/IP Connection Procedure In the PLC IO Table Window, click on + to the left of Built-in Port/Inner Board. CJ1W-EIP21 is shown. * The figure on the right is the CPU Unit (built-in EtherNet/IP port) shown in 5.2. Device Configuration.
  • Page 29 7. EtherNet/IP Connection Procedure A confirmation dialog box as shown in the figure on the right appears. Confirm that there is no problem and click Yes. Confirm that Transfer successful is displayed and click Close. A confirmation dialog box as shown in the figure on the right appears.
  • Page 30 7. EtherNet/IP Connection Procedure Click Compare to confirm that the IP address is correctly changed. Confirm that Compare successful is displayed and click Close. Click OK in the Edit Parameters Dialog Box.

  • Page 31: Network Setup

    7. EtherNet/IP Connection Procedure 7.4. Network Setup Set up the EtherNet/IP Tag data links. 7.4.1. Starting the Network Configurator and Going Online with the PLC Start the Network Configurator and go online with the PLC. In the PLC IO Table Window, right-click on CJ1W-EIP21 and select Start Special Application –...
  • Page 32 7. EtherNet/IP Connection Procedure Precautions for Correct Use Before performing the following steps, confirm that the LAN cable is connected securely. If it is not connected, first turn OFF the power supply to the device and then connect the LAN cable.
  • Page 33 7. EtherNet/IP Connection Procedure If the Network Configurator is successfully connected online, the dot next to the network name turns blue. Note If you cannot go online with the PLC, check the physical cable connections, etc. If the physical cable connections are correct, return to step 3 and follow the setup procedures again.
  • Page 34 Installing the EDS File Install the EDS file for V330-F/V430-F. The EDS file can be downloaded from the OMRON web page. Note that, for V430, the required EDS file differs depending on the version. Select Install from the EDS File Menu.
  • Page 35 7. EtherNet/IP Connection Procedure 7.4.3. Uploading the Network Configuration Upload the configuration for devices on the network. Select Upload from the Network Menu to upload parameters of the devices on the network. A confirmation dialog box as shown in the figure on the right appears.
  • Page 36 7. EtherNet/IP Connection Procedure When the upload of the device parameters is complete, a confirmation dialog box as shown in the figure on the right appears. Read the information and click OK. In the Network Window after the upload, confirm that the IP address setting for each node is updated as follows.
  • Page 37 7. EtherNet/IP Connection Procedure 7.4.4. Setting the Tags Register the tags for the Send area and Receive area. Here, the procedure for setting the Receive area and Send area for the target node are described in this order. In the Network Configurator, right-click on the Node 1 device in the Network Window and select Parameter –...
  • Page 38 7. EtherNet/IP Connection Procedure The Edit Tags Dialog Box is displayed. Select the In - Consume Tab and click New. Here, register the tags for the Receive area where Node 1 receives input data (Node 2 → Node 1). The Edit Tag Dialog Box is displayed.
  • Page 39 7. EtherNet/IP Connection Procedure Click the Out – Produce Tab and click New. Here, register the tags for the Send area where Node 1 sends output data (Node 1 → Node 2). The Edit Tag Dialog Box is displayed. Enter parameter values as follows.
  • Page 40 7. EtherNet/IP Connection Procedure After registering the tags, click OK in the Edit Tags Dialog Box. A confirmation dialog box as shown in the figure on the right appears. Confirm that there is no problem and click Yes. You are returned to the Edit Parameters Dialog Box.
  • Page 41 7. EtherNet/IP Connection Procedure 7.4.5. Setting Up the Connections For the registered tags, configure the settings to associate the tags for the target device (side on which connections are to be established) with the tags for the originator (side on which you want to establish connections).
  • Page 42 7. EtherNet/IP Connection Procedure Confirm that the settings are correct, and click Regist. The Edit Connection Dialog Box is displayed again. Click Close. You are returned to the Edit Device Parameters Dialog Box. Click OK. When connection assignment is completed, the registered node address is displayed under the device icon for Node 2 in the Network Window.
  • Page 43 7. EtherNet/IP Connection Procedure 7.4.6. Transferring the Tag Data Link Parameters Transfer the set tag data link parameters to the PLC. Right-click on the Node 1 device in the Network Window and select Parameter – Download. A confirmation dialog box as shown in the figure on the right appears.

  • Page 44: Checking The Ethernet/Ip Communications

    7. EtherNet/IP Connection Procedure 7.5. Checking the EtherNet/IP Communications Check that the EtherNet/IP tag data links are operating normally. 7.5.1. Checking the Connection Status Check the EtherNet/IP connection status and display the WebLink screen. Check the LED indicators on the PLC (EtherNet/IP Unit) to confirm that the EtherNet/IP tag data links are operating normally.
  • Page 45 7. EtherNet/IP Connection Procedure Select Disconnect from the Network Menu to go offline. The blue dot next to the network name changes to gray. Select Exit from the File Menu to exit the Network Configurator. Start your browser and enter http://192.168.188.2.
  • Page 46 7. EtherNet/IP Connection Procedure 7.5.2. Checking the Sent and Received Data Check that the correct data is sent and received. If PLC memory is unintentionally changed by mistake during continuity/current value monitoring in the ladder section window or watch window, the connected devices may operate regardless of the operating mode of the CPU Unit.
  • Page 47 7. EtherNet/IP Connection Procedure The PLC Memory Window is displayed. Double-click D from the list in the left pane of the PLC Memory Window. Select Display – Binary from the View Menu. Select Monitor from the Online Menu. The Monitor Memory Areas Dialog Box appears.
  • Page 48 7. EtherNet/IP Connection Procedure Select Bit 1 of D11000 and click On. (This changes the value to 1.) After that, select Bit1 of D11000 again and click Off. * The first bit of D11000 corresponds to the Trigger bit of the Output Assembly.

  • Page 49: Initializing The System

    8. Initializing the System 8. Initializing the System In this document, it is assumed that the controller and the code reader uses the factory default settings. If you change their settings from the default, you may not be able to perform various setting procedures as described.

  • Page 50: Initializing The Code Reader

    8. Initializing the System (3) An execution confirmation dialog box appears. Confirm that there is no problem and click Yes. Next, the Restart Unit Dialog Box is displayed. Select Return to out-of-box configuration, and then emulate cycling power and click OK. An execution completion dialog box appears.

  • Page 51: Revision History

    9. Revision History 9. Revision History Revision Code Revision Date Revised Page and Reason July 2022 First Publication...
  • Page 52 9. Revision History...
