3 Controlling Operation and Data Output with Ethernet
3-1-4

Communication Settings (EtherNet/IP)

Using WebLink to Set the Code Reader Network Settings
Use WebLink to set the IP address on the code reader to match the network settings of the PLC or
other external device.
• WebLink - Setup - Gear Icon - Advanced Settings - Communications - Ethernet
1
Set Ethernet to Enabled.
2
Set the IP Address and Subnet mask according to the network settings of the PLC or other
external device.
Setting Item
Ethernet
IP Address
Subnet
Gateway
IP Address Mode
3-6
Autofocus Multicode Reader MicroHAWK V320-F/V330-F/V420-F/V430-F Series User Manual for Communication Settings (Z407-E1)
Setting Value
•
Enabled Select whether to enable all, some, or none of the various
Ethernet protocols, (Serial (TCP)), EtherNet/IP, PROFINET).
(Default)
•
Disabled
a.b.c.d Enter the IP address of the Code Reader
a: 0 to 255
b: 0 to 255
c: 0 to 255
d: 0 to 255
(Default:
192.168.188.2)
a.b.c.d Input the subnet mask address.
a: 0 to 255
b: 0 to 255
c: 0 to 255
d: 0 to 255
(Default:
255.255.0.0)
a.b.c.d If a Gateway is used, enter the gateway address. If a Gate-
a: 0 to 255 way is not used, use the default value 0.0.0.0.
b: 0 to 255
c: 0 to 255
d: 0 to 255
(Default: 0.0.0.0)
•
Fixed In Fixed mode, the code reader uses a user-defined IP ad-
dress.
(Default)
•
In DHCP mode, the code reader acquires its IP address,
DHCP
subnet, and gateway from the DHCP server.
Description
