Member Name
Exposure Done
Decoding
Data is Ready
Read Cycle Pass
Read Cycle Fail
General Fault
Matchcode Master Label
Changed
Matchcode Enabled
Image Sensor Calibrating
Image Sensor Calibration
Complete
Training
Training Complete
Optimizing
Optimizing Complete
Auto Image Photometry Ena-
bled
Auto Image Photometry Com-
plete
Output 1 Status
Output 2 Status
Output 3 Status
BufferOverflow
Reserved
Fault Code
Command Error Detected
Communication Error
Reserved
Host Port Buffer Overflow
Reserved
Counters
No Read Read Cycle Counter
Mismatch per Read Cycle
Counter
No Read Counter
Trigger Counter
Matchcode Counter
Mismatch Counter
Read Cycle Report
Capture Time
Total Decode Time
Total Read Cycle Time
Reserved
Decode 1 Cycle Report
Data Type Bit Number
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22 - 31
DINT
0
1
2
3
4 - 31
UDINT[6]
0 - 31
0 - 31
0 - 31
0 - 31
0 - 31
0 - 31
UINT[4]
0 - 15
0 - 15
0 - 15
0 - 15
Data Length Byte Offset
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
10 bit
4 Byte 8
1 bit
1 bit
1 bit
1 bit
28 bit
24 byte 12
4 byte
4 byte
4 byte
4 byte
4 byte
4 byte
8 byte 36
2 byte
2 byte
2 byte
2 byte
8 byte 44
