Appendices
Numeric value in Bit
0 = OFF
1 = ON
• External Output Status
Indicates the current state of the Parallel Output signal.
0
1
2
3 - 31
Numeric value in Bit
0 = OFF
1 = ON
• Device status
Displays code reader Status
Bit
0
1
2 - 7
8
9 - 15
16
17
• Read Cycle Sequence Counter
Stores the current Read Cycle Count.
• Trigger Counter
Stores the current total number of triggers input.
• Decode/Matchcode Counter
Stores one of the following.
1. Total number of Good Reads (When Matchcode: Disabled)
2. Total number of matches to the Master Symbol (When Matchcode: Enabled)
• Mismatch Counter
Stores the total number of Mismatches (not matching Master Symbol).
• No Read Counter
Stores the total number of No Reads.
• Decode Data Length
Stores the number of characters in the Read string.
• Decode Data String
Stores the Read string. When additional information such as Print Quality Grading Standard is set, it
is stored following the Read string.
A-6
Autofocus Multicode Reader MicroHAWK V320-F/V330-F/V420-F/V430-F Series User Manual for Communication Settings (Z407-E1)
Bit
OUTPUT 1
OUTPUT 2
OUTPUT 3
Reserved
State
Reserved
New Master Requested
Reserved
Scanning Disabled
Reserved
In Read Cycle
Actively Scanning
Signal Name
Description
-
When the bit is ON, the next read result is registered
as the Master Symbol.
-
When the bit is ON, the Read Cycle is Disabled.
-
Bit is ON when In Read Cycle.
When the bit is ON, the Read Cycle is Disabled.
