2.2. Rotating Unit Part

VT-TECH-Smart Plus-001
SUB015
DC POWER
BOARD
BOARD
(LASER)
(DC-04)
CT/PANO
SENSOR
(Xmaru1404CF-Plus)
14 / 188
Smart Plus (PHT-35LHS)
Technical Manual
COLLIMATOR
MCU
BOARD
(MCU006)
INVERTER
BOARD
SUB046
BOARD
(ROTATOR)
COPYRIGHT© 2018 VATECH
ALL RIGHTS RESERVED
.
